VLT® Refrigeration Drive FC 103
Operating Guide
1
2
3
4
Illustration 5: Visual Representation of a D10h Enclosure and the Locations of Available Options
1
Passive harmonic filter (PHF)
2
Line reactor
3
Non-fusible disconnect
4
Fusible disconnect
5
Molded-case circuit breaker (MCCB)
Danfoss A/S © 2020.09
10
6
5
6
7
8
9
10
9
8
7
Mains contactor
dU/dt filter
Common-mode filter
Sine-wave filter
Drive module (varies in power rating)
AQ357954340588en-000201 / 130R0881 | 17
Product Overview
