VLT® Refrigeration Drive FC 103
Operating Guide
Model Enclosure size (380–480 V)
N630 –
N710 –
N800 –

3.4.3 Type Code Identification

Table 4: Product Group Code
Character position
1–3
Table 5: Drive Series Codes
Character position
4–6
Table 6: Low-harmonic Filter Codes
Character position
7
Table 7: Mains Voltage Codes
Character position
8
Table 8: Norms and Standards Codes
Character position
9
Table 9: Power Rating Codes
Character position
10–12
20 | Danfoss A/S © 2020.09
Code
PLV
Code Description
®
102 VLT HVAC Drive FC 102
®
103 VLT Refrigeration Drive FC 103
®
202 VLT AQUA Drive FC 202
®
302 VLT AutomationDrive FC 302
Code Description
T None
P Passive filter, THDi=5%, 50 Hz
H Passive filter, THDi=8%, 50 Hz
L Passive filter, THDi=5%, 60 Hz
U Passive filter, THDi=8%, 60 Hz
Code Description
4 380–480 V
5 380–500 V
7 525–690 V (525–600 V for UL)
Code
I
U
Code Description
90K (N90K) 90 kW/125 hp
Enclosure size (525–690 V)
E5h
E6h
E6h
Description
®
VLT Enclosed Drives
Description
IEC
UL
AQ357954340588en-000201 / 130R0881
Product Overview
