Character position
Table 17: Auxiliary Power Supply Codes
Character position
21
Table 18: Back-channel Cooling Codes
Character position
22
Table 19: Auxiliary Function Codes
Character posi- Code
tion
23–24 AX
A1
A2
A3
A4
A5
AA
AB
AC
AD
AE
Danfoss A/S © 2020.09
Code
M
Code
1
2
4
5
6
7
8
9
Code
X
1
C
D
N
Description
No auxiliary options
AC socket+cabinet light
Extended I/O terminals
Cabinet heater
Motor heater control
Insulation monitor
AC socket + cabinet light + extended I/O terminals
AC socket + cabinet light + cabinet heater
AC socket + cabinet light + motor heater control
AC socket + cabinet light + insulation monitor
AC socket + cabinet light + extended I/O terminals + cabinet heater
Description
Mains bottom, motor top
Description
230 V AC external
230 V AC internal
230 V AC internal + 24 V DC internal
230 V AC external + 24 V DC internal
120 V AC external
120 V AC internal
120 V AC internal + 24 V DC internal
120 V AC external + 24 V DC internal
Description
Bottom in, top out
Back in, back out
Back in, top out
Bottom in, back out
None
