VLT® Refrigeration Drive FC 103
Operating Guide
1
-XD4.1
2
-XDL.1
3
-XD11.3
4
-XD4.3
5
R
S T
6
L1R L2S L3T
Illustration 32: Split Shipment Electrical Connections (Input Power Options Cabinet + E5h Drive Cabinet)
1 Cabinet heater supply harness to input filter cabinet
2 DC-link harness to fan supply in input filter cabinet
3 Thermal protection harness to input filter cabinet
4 PHF contactor 1 supply harness to input filter cabi-
net (only with PHF option)
5 Mains cables (R/S/T) to input terminals (R/S/T) in the
input filter cabinet
Danfoss A/S © 2020.09
-XD11.1
7
8
-XD4.1
6 Mains cables (L1R/L2S/L3T) to output terminals
(L1R/L2S/L3T) in the input filter cabinet
7 DC-link harness to fan supply to output filter cabinet
8 Cabinet heater supply harness to output filter cabi-
net
9 Available terminal connections
10 Thermal protection wiring harness to output filter
cabinet
Electrical Installation
-XDL.1
AQ357954340588en-000201 / 130R0881 | 61
9
10
