Input Power Option Losses; Contactor Losses - Danfoss VLT FC 103 Operating

VLT® Refrigeration Drive FC 103
Operating Guide
-RFI Radio frequency interference (RFI) filter
R1 Resistor
-RF5 Passive harmonic filter (PHF) L0
-RF4 PHF inductors
-CA5 PHF capacitors
-QA2 PHF contactor
-RFL Line reactor
-QAF PHF relay
-QB7 Molded-case circuit breaker (MCCB)
-QA3 Mains contactor
-QB2 Mains fused disconnect

11.6 Input Power Option Losses

11.6.1 Contactor Losses

Table 135: Power Losses for Contactor Option, 380–480 V (Losses Shown in Watts)
Model
–
N110
N132
N160
N200
N250
N315
N355
N400
N450
N500
N560
Table 136: Power Losses for Contactor Option, 525–690 V (Losses Shown in Watts)
Model
–
N110
N132
N160
Danfoss A/S © 2020.09
380–440 V
NO HO
16 11
25 16
36 25
57 36
42 28
63 42
62 51
79 62
91 69
74 61
94 74
525–550 V
NO HO
7 5
10 7
15 10
-QB8 Mains disconnect
-MA7 dU/dt and sine-wave filter fans
-MA8 PHF fans
-RF2 Sine-wave filter inductor
-CA4 Sine-wave filter capacitor
-RF1 dU/dt filter inductor
-CA3 dU/dt filter capacitor
-RF3 Common-mode filter
-MA1 Motor (customer side)
-TA1 Drive module
LCP Local control panel
441–480 V
NO
13
21
33
47
36
52
50
66
76
58
76
551–690 V
NO
6
9
13
AQ357954340588en-000201 / 130R0881 | 173
Appendix
HO
9
13
21
33
24
36
42
50
66
51
58
HO
4
6
9
