VLT® Refrigeration Drive FC 103
Operating Guide
1
2
3
-XD11.1
4
-XD4.1
Illustration 36: Split Shipment Electrical Connections (E5h/E6h Sine-wave Cabinets)
1
Additional terminal connections
2
Thermal protection wiring harness to drive cabinet
3
DC-link harness to fan power supply in drive cabinet
Danfoss A/S © 2020.09
-XDL.1
U
V
W
U
4
5
V
W
5
Cabinet heater supply harness to drive cabinet
Motor cables (U/V/W) to motor terminals (U/V/W) in
drive cabinet
AQ357954340588en-000201 / 130R0881 | 65
Electrical Installation
