VLT® Refrigeration Drive FC 103
Operating Guide
Character posi- Code Description
tion
AP Extended I/O terminals + cabinet heater
AQ Extended I/O terminals + motor heater control
AR Extended I/O terminals + insulation monitor
AS Extended I/O terminals + cabinet heater + motor heater control
AT Extended I/O terminals + cabinet heater + insulation monitor
AU Extended I/O terminals + cabinet heater + motor heater control + insulation monitor
AV Extended I/O terminals + motor heater control + insulation monitor
The extended I/O terminal option includes 25 control terminals (-XDW) in the control compartment for use by the customer. If the
enclosed drive is configured with any option C1 card, the -XDW terminal block is used for the option C1 card wiring.
5.7.6.6 Cabinet Heater
Table 59: Auxiliary Function Type Codes
Character posi- Code
tion
23–24 A3
AB
AE
AH
AI
AK
AL
AM
AN
AP
AS
AT
AU
AW
A8
AY
The cabinet heater option increases the inside temperature of the cabinet above the ambient temperature, preventing condensa-
tion in the cabinet. Each cabinet has 1 cabinet heater. The heater element is self regulating. The external supply is connected to
terminal -XD1.1. When the drive is not in run state, the control relay -QAM changes the supply to the output terminals (-XD4). When
the drive is in run state, the control relay disconnects the supply to the cabinet heater. The function is disabled when MCB –FCE is
open.
78 | Danfoss A/S © 2020.09
Description
Cabinet heater
AC socket + cabinet light + cabinet heater
AC socket + cabinet light + extended I/O terminals + cabinet heater
AC socket + cabinet light + extended I/O terminals + cabinet heater + motor heater control
AC socket + cabinet light + extended I/O terminals + cabinet heater + insulation monitor
AC socket + cabinet light + extended I/O terminals + cabinet heater + motor heater control + insula-
tion monitor
AC socket + cabinet light + cabinet heater + motor heater control
AC socket + cabinet light + cabinet heater + insulation monitor
AC socket + cabinet light + cabinet heater + motor heater control + insulation monitor
Extended I/O terminals + cabinet heater
Extended I/O terminals + cabinet heater + motor heater control
Extended I/O terminals + cabinet heater + insulation monitor
Extended I/O terminals + cabinet heater + motor heater control + insulation monitor
Cabinet heater + motor heater control
Cabinet heater + insulation monitor
Cabinet heater + motor heater control + insulation monitor
Electrical Installation
