VLT® Refrigeration Drive FC 103
Operating Guide
Electrical Installation
U
V
W
1
Illustration 25: Split Shipment Electrical Connections (Top Exit Cabinet)
1
Motor cables (U/V/W) to motor terminals (U/V/W) in drive cabinet
54 | Danfoss A/S © 2020.09
AQ357954340588en-000201 / 130R0881
