Connecting The Sine-Wave Filter To The Motor - Danfoss VLT FC 103 Operating

VLT® Refrigeration Drive FC 103
Operating Guide
4. Connect the ground wire to the nearest grounding terminal in accordance with the grounding instructions provided in
5.8.6 Connecting to
5. Connect the 3-phase AC motor cables to terminals U (T1), V (T2), and W (T3).
6.
Tighten the terminals in accordance with the specifications shown in
Example
1
2
3
4
5
6
Illustration 50: Connection Points for Drive Module to Motor (E6h Model Shown)
1 Lower cover
2 DC terminals
3 Terminal cover

5.8.4 Connecting the Sine-wave Filter to the Motor

Danfoss A/S © 2020.09
Ground.
10.11 Fastener Torque
4 Motor terminals
5 Ground terminals on drive module
6 Grounding bar
AQ357954340588en-000201 / 130R0881 | 85
Electrical Installation
Ratings.
