3.3 Location of Options within an Enclosed Drive

1
2
3
4
Illustration 4: Visual Representation of a D9h Enclosure and the Locations of Available Options
1 Passive harmonic filter (PHF)
2 Line reactor
3 Non-fusible disconnect
4 Fusible disconnect
5 Molded-case circuit breaker (MCCB)
16 | Danfoss A/S © 2020.09
10
6
5
6
7
8
9
10
9
8
7
Mains contactor
dU/dt filter
Common-mode filter
Sine-wave filter
Drive module (varies in power rating)
