Table 51: Option C1 Terminal Connections for VLT® Extended Relay Card MCB 113
Option card terminal
X45.1
X45.2
X45.3
X45.4
X46.1
X46.2
X46.3
X46.4
X46.5
X46.6
X46.7
X46.8
X46.9
X46.10
X46.11
X46.12
X46.13
X46.14
X47.1
X47.2
X47.3
X47.4
X47.5
X47.6
X47.7
X47.8
X47.9
X47.10
X47.11
X47.12
X58.1
X58.2
Danfoss A/S © 2020.09
Corresponding terminal within the control compartment
XDF.17
XDF.18
XDF.19
XDF.20
XDF.1
XDF.2
XDF.3
XDF.4
XDF.5
XDF.6
XDF.7
XDF.8
XDF.9
XDF.10
XDF.11
XDF.12
XDF.13
XDF.14
XDF.21
XDF.22
XDF.23
XDF.24
XDF.25
XDF.26
XDF.27
XDF.28
XDF.29
XDF.30
XDF.31
XDF.32
XDF.15
XDF.16
Electrical Installation
