Specifications

8 Specifications

8.1 Electrical Data

8.1.1 Mains Supply 3x200-240 V AC

Type Designation
Typical Shaft Output [kW]
Typical Shaft Output [HP] at 208 V
6)
IP20/Chassis
IP55/Type 12
IP66/NEMA 4X
Output current
Continuous (3x200-240 V) [A]
Intermittent (3x200-240 V) [A]
Continuous kVA (208 V AC) [kVA]
Max. input current
Continuous (3x200-240 V) [A]
8 8
Intermittent (3x200-240 V) [A]
Additional specifications
Estimated power loss at rated max. load [W]
IP20, IP21 max. cable cross-section (mains, motor, brake and load
sharing) [mm 2 /(AWG)]
IP55, IP66 max. cable cross-section (mains, motor, brake and load
2
sharing) [mm /(AWG)]
Max. cable cross-section with disconnect
Efficiency 3)
Table 8.1 Mains Supply 3x200-240 V AC - Normal overload 110% for 1 minute, P1K1-P3K7
42
Operating Instructions
P1K1
A4/A5
A4/A5
2.38
4)
0.96
Danfoss A/S © Rev. 2014-02-06 All rights reserved.
P1K5 P2K2
1.1 1.5 2.2
1.5 2.0 2.9
A2 A2 A2
A4/A5 A4/A5
A4/A5 A4/A5
6.6 7.5 10.6
7.3 8.3 11.7
2.70 3.82
5.9 6.8 9.5
6.5 7.5 10.5
63 82 116
4, 4, 4 (12, 12, 12)
(min. 0.2 (24))
4, 4, 4 (12, 12, 12)
6, 4, 4 (10, 12, 12)
0.96 0.96
P3K0 P3K7
3.0 3.7
4.0 4.9
A3 A3
A5 A5
A5 A5
12.5 16.7
13.8 18.4
4.50 6.00
11.3 15.0
12.4 16.5
155 185
0.96 0.96
