VLT® Refrigeration Drive FC 103
Operating Guide
Table 126: MCCB Part Numbers for N400–N630 Models, 525–690 V
N400 N450
600 A/690 V 1000 A/690 V
IEC
ABB P/N T6L630T T7L1000LSPR23 1 DS-
LS
600 A/600 V 1000 A/600 V
UL
ABB P/N T6LQ600TW T7L1000PR231/P
Table 127: MCCB Part Numbers for N710–N800 Models, 525–690 V
N710
IEC 1250 A/690 V
ABB P/N T7L1250LSPR23 1 DS-LS
1200 A/600 V
UL
ABB P/N T7L1200PR231/ P

10.9 Enclosure Dimensions

10.9.1 Pedestal Dimensions

The pedestal, on which the enclosure sits, is available in 3 different heights:
• 100 mm (3.9 in)
• 200 mm (7.9 in)
• 400 mm (15.8 in)

10.9.2 D9h Enclosed Drive Exterior Dimensions

55 (2.2)
1
2000
(78.7)
4
100 (3.9)
400 (15.8)
600 (23.6)
Illustration 72: Dimensions for D9h Enclosure with Standard Pedestal
Danfoss A/S © 2020.09
N500 N560
1000 A/690 V 1000 A/690 V
T7L1000LSPR23 1 DS- T7L1000LSPR23 1 DS-LS
LS
1000 A/600 V 1200 A/600 V
T7L1000PR231/P T7LQ1200PR231/P
N800
1250 A/690 V
T7L1250LSPR23 1 DS-LS
1200 A/600 V
T7L1200PR231/ P
2
400 (15.8)
Specifications
N630
1000 A/690 V
T7L1000LSPR23 1 DS-LS
1200 A/600 V
T7LQ1200PR231/P
3
600 (23.6)
AQ357954340588en-000201 / 130R0881 | 161
