VLT® Refrigeration Drive FC 103
Operating Guide
1
2
5
Illustration 3: Possible Configurations for an E5h or E6h Enclosed Drive
1
Input filter cabinet (passive harmonic filter or line re-
actor)
2
Input power options cabinet
3
Drive cabinet
Danfoss A/S © 2020.09
3
3
4
6
4
Sine-wave filter cabinet
5
Control compartment
6
dU/dt filter cabinet
AQ357954340588en-000201 / 130R0881 | 15
Product Overview
