11.6.6 dU/dt Filter Losses

Table 145: Power Losses for dU/dt Filter Option, 380–480 V (Losses Shown in Watts)
Model
–
N110
N132
N160
N200
N250
N315
N355
N400
N450
N500
N560
Table 146: Power Losses for dU/dt Filter Option, 525–690 V (Losses Shown in Watts)
Model
–
N110
N132
N160
N200
N250
N315
N355
N400
178 | Danfoss A/S © 2020.09
525–550 V
3075 2800
3380 3075
3720 3380
4242 3720
4600 4242
5700 4600
380–440 V
NO HO
350 244
526 350
327 223
514 327
834 565
1251 834
713 593
914 713
1054 795
1402 1158
1774 1402
525–550 V
NO HO
453 308
204 146
314 204
498 314
302 211
427 302
575 427
800 565
551–690 V
3075 2800
3380 3075
3720 3380
4242 3720
4600 4242
5700 4600
441–480 V
NO HO
281 199
448 281
300 190
429 300
710 472
1036 710
573 480
757 573
878 757
1101 964
1434 1101
551–690 V
NO
414
187
287
456
277
390
527
733
