Chapter 4. Installing a New Standalone Library on a Desktop

|
| |
|

"Unpacking and Verifying Shipment Contents"

|
"Reducing Weight" on page 4-5
"Preparing the Library Module(s) for Installation" on page 4-7
|
|
"Installing Library Foot Pads" on page 4-12
"Installing Additional Modules in Your Library Configuration" on page 4-14
|
"Enabling the Picker Assembly" on page 4-17
|
"Installing Library Components Removed for Weight Reduction" on page 4-18
|
"Cabling the Library" on page 4-21
|
"Powering ON the Library" on page 4-26
|
|
|
|
|
|
|
|
|
|
|
|
|
Unpacking and Verifying Shipment Contents
|
| |
|
|
|
|
|
|
|
|
|
|
|
|
| |
| |
| |
| |
| | |
| | |
| | |
|
© Copyright IBM Corp. 2005, 2006
Follow the steps in this chapter to install a new a new 5U or 14U library on a
desktop. For instructions on converting your rack-mounted 5U or 14U library to a
desktop unit or converting a 5U or 14U desktop library to a rack-mounted library,
see "Library Conversions" on page 12-26. For instructions on removing or
replacing a control module or expansion module, see "Removing/Replacing a
Control Module" on page 12-2 and "Removing/Replacing an Expansion Module"
on page 12-11.
Note: A desktop library can only support one expansion module. If you have two
or more expansion modules, you must install the library in a rack.
Important: Because of the weight of a multi-module library, it is strongly
recommended that you install it in the lowest position in a rack. Without
drive sleds and power supplies, a control module weighs approximately
18-32 kg (39.7-70.5 lbs)
50 lbs. Without drive sleds and power supplies, each 9U expansion
module weighs approximately 65 lbs.
1. Open and unpack all the boxes in your shipment.
2. Remove all external packaging materials from around the library module.
Note: Leave the library module on the lifting sling until it is ready to be
installed.
3. Verify the contents of your shipment.
Table 4-1. Shipment contents
Description
Library control module 5U
Expansion module E9U (maximum 1 expansion module per
desktop library)
Number Number for
for each each
control expansion
module module
1
1
