IBM System Storage TS1140 Tape Drive Model E07
delivers higher performance, reliability, and capacity
Table of contents
1
Overview
2
2
2
5
6
At a glance
With its higher performance and greater capacity as compared to TS1130 Tape Drive
Model E06, the use of the TS1140 Tape Drive can help save costs as the number of
tape drives, cartridges, and associated floor space are all reduced. Enhancements of
the TS1140 Tape Drive include:
•
Native data rate performance of up to 250 MB/sec (up to 650 MB/sec
compressed) versus the 160 MB/sec native data rate of TS1130 Tape Drive Model
E06
•
Uncompressed cartridge formatting of up to 4.0 TB (12.0 TB with 3:1
compression) with the use of IBM® Tape Cartridge 3592 Advanced Data (Type C)
•
Dual Fibre Channel interface at 8 Gbps designed to enhance attachment flexibility
•
Effective media reuse with capacity to read and write up to N-1 generation media
•
Encryption capabilities designed to work with the IBM Tivoli® Key Lifecycle
Manager
•
Small form factor to help improve space efficiency of tape infrastructure
•
High availability design
The high reliability of the 3592 tape drive and media is maintained and improved
with these features:
•
Giant Magneto Resistive (GMR) 32-channel head technology
•
Media partitioning capability setting the grounds for improved data management
on tape
•
Virtual backhitch improvements for increased performance avoids the backhitch
of the tape
For ordering, contact your IBM representative, an IBM Business Partner, or IBM
Americas Call Centers at 800-IBM-CALL (Reference: YE001).
Overview
IBM System Storage® TS1140 Tape Drive Model E07 (machine type 3592) is
the fourth generation of the highly successful IBM 3592 Enterprise Tape Drive. It is
supported for integration in the IBM System Storage TS3500 Tape Library or racks
that enable stand-alone installations.
The TS1140 Tape Drive is designed to provide higher levels of performance,
reliability, and cartridge capacity than the TS1130 Model E06 Tape Drive. It has
IBM United States Hardware Announcement 111-087
IBM United States Hardware Announcement
111-087, dated May 9, 2011
7
8
13
15
17
IBM is a registered trademark of International Business Machines Corporation
1
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for IBM TS1140
Summary of Contents for IBM TS1140
-
Page 1: Table Of Contents
With its higher performance and greater capacity as compared to TS1130 Tape Drive Model E06, the use of the TS1140 Tape Drive can help save costs as the number of tape drives, cartridges, and associated floor space are all reduced. Enhancements of the TS1140 Tape Drive include: •... -
Page 2: Key Prerequisites
250 MB/sec versus the 160 MB/sec data rate of the TS1130 Tape Drive Model E06. The TS1140 E07 Tape Drive has a dual-port 8-Gbps Fibre Channel interface for Fibre Channel attachment to host systems or a switched fabric environment. - Page 3 NA = Not Applicable Performance TS1140 E07 uses a design that increases the native data rate up to 250 MB/sec (up to 650 MB/sec compressed) versus the 160 MB/sec data rate of TS1130 Tape Drive Model E06. It is designed to offer improved access characteristics in search velocity and rewind time versus the TS1130 E06, with other enhancements designed to help aid small file and Hierarchical Storage Manager performance.
- Page 4 Solaris, and Microsoft Windows IBM tape device drivers. The failover mechanism is designed to enable configuration of multiple redundant paths in a SAN environment that includes the TS1140. In the event of a path or component failure, the failover mechanism is designed to automatically enable error recovery to retry the current operation using an alternate, preconfigured path without aborting the current job in progress.
-
Page 5: Product Positioning
Model Tape Drives: • Large internal data buffer: The TS1140 E07 Tape Drive has a 1 GB internal data buffer. Along with enabling higher performance characteristics, the data buffer is designed to use support read ahead of compressed data from tape and provide high performance random skip forward sequential (short hop) locates common in database search and tape software recycle operations. -
Page 6: Product Number
– Environments where both streaming and start/stop (access), large and small file workloads are required. Other target customers for the TS1140 Tape Drive are encryption opportunities in medium to large enterprises in the financial sector, government and public sector, and other industries that must protect their customer tape data from loss or theft. -
Page 7: Publications
Parts removed as a result of a model conversion become the property of IBM. Business Partner information If you are a Direct Reseller - System Reseller acquiring products from IBM, you may link directly to Business Partner information for this announcement. A PartnerWorld ID and password are required (use IBM ID). -
Page 8: Technical Information
Each TS1140 E07 Tape Drive comes with GMR head technology and dual-ported switched fabric 8 Gbps Fibre Channel attachments, for attachment to multiple servers or a single server with redundancy. It can be attached to IBM Power Systems, IBM System i, IBM System p, IBM System x and other servers running... - Page 9 Refer to 3592 Sales Manuals for further information. Up to twelve TS1140 drives can be installed in a 3584 Model L22, L23, D22, or D23 frame. The 3584 Model L22 or L23 Base Frame and Model D22 or D23 Expansion Frame are designed for TS1140 Model E07, TS1130 Model E06, TS1120 Model E05, and 3592 Model J1A Tape Drives and 3592 cartridges.
- Page 10 The attaching fiber cable must be 50.0/125 micrometers for distances up to 150 meters at 8 Gbps. The connector on the TS1140 E07 Tape Drive is a LC duplex connector type. The Fibre Channel cables with LC or SC duplex connectors...
- Page 11 TS1140 Tape Drive (3592 E07) support: Feature #0500 Drive Microcode Update Fibre Channel Switch attachment The TS1140 E06 Tape Drive is supported by a variety of Fibre Channel Switches and Fibre Channel Directors. The support is dependent on server, operating system, and host bus adapter that is being used.
- Page 12 Machine Code (microcode, basic input/output system code (called BIOS), utility programs, device drivers, and diagnostics delivered with an IBM machine) and other software updates in a timely manner from an IBM Internet Web site or from other electronic media, and following the instructions that IBM provides. You may request IBM to install Machine Code changes;...
-
Page 13: Terms And Conditions
An IBM part or feature installed during the initial installation of an IBM machine is subject to a full warranty effective on the date of installation of the machine. An IBM part or feature which replaces a previously installed part or feature assumes the remainder of the warranty period for the replaced part or feature. - Page 14 On-site Service IBM will repair the failing machine at your location and verify its operation. You must provide a suitable working area to allow disassembly and reassembly of the IBM machine. The area must be clean, well lit, and suitable for the purpose.
-
Page 15: Pricing
Model conversions Machine installation Installation is performed by IBM. IBM will install the machine in accordance with the IBM installation procedures for the machine. In the United States, contact IBM at 1-800-IBM-SERV (426-7378). In other countries, contact the local IBM office. - Page 16 Prices in the following PDF prices link are suggested list prices on day of announcement for the U.S. only. They are provided for your information only. Dealer prices may vary, and prices may also vary by country. IBM list price does not include tax or shipping and is subject to change without notice.
-
Page 17: Order Now
Order now To order, contact the Americas Call Centers or your local IBM representative, or your IBM Business Partner. To identify your local IBM representative or IBM Business Partner, call 800-IBM-4YOU (426-4968). - Page 18 IBM products and services which are announced and available in your country can be ordered under the applicable standard agreements, terms, conditions, and prices in effect at the time. IBM reserves the right to modify or withdraw this announcement at any time without notice. This announcement is provided for your information only.
