Page 1 IBM System Storage TS3500 Tape Library with ALMS Introduction and Planning Guide GA32-0593-07...
Page 2 “Notices” on page 223. Edition notice This edition applies to the eighth release of the IBM System Storage TS3500 Tape Library with ALMS Introduction and Planning Guide and to all subsequent releases and modifications until otherwise indicated in new editions.
Page 3: Table Of Contents
. xii Insert notification setting . . 49 Send us your feedback . . xiii Power structure of the TS3500 Tape Library . 50 Frame control assembly and dual ac power. . 50 Safety and environmental notices . . . xv Enhanced frame control assembly .
Page 4 . 152 numbers . . 196 Guidelines for using Ultrium bar code labels Ordering supplies for repairs . . 197 Ordering 3592 bar code labels . . 198 IBM System Storage TS3500 Tape Library with ALMS: Introduction and Planning Guide...
Page 5 Taiwan Class A compliance statement . . 228 Connectors and adapters . 207 Taiwan contact information. . 228 Connecting the library to IBM i, System i, and Japan Voluntary Control Council for Interference iSeries . . 208 (VCCI) Class A Statement . . 228 Sharing drives on a Storage Area Network .
Page 6 IBM System Storage TS3500 Tape Library with ALMS: Introduction and Planning Guide...
Page 7: Figures
. 126 Library . Types of receptacles for power cords used by Location of service bays in the TS3500 Tape Models L22, D22, L52, and D52 of the TS3500 Library . Tape Library . . 128 Cartridge slots in the service bays of the TS3500...
Page 8 IBM System Storage TS3500 Tape Library with ALMS: Introduction and Planning Guide...
Page 9: Tables
TS3500 Tape Library configurations . Physical characteristics of the TS3500 Tape TS3500 Tape Library frame models . LibraryModel S24 . 98 Tape drives that are supported by the TS3500 Physical characteristics of the TS3500 Tape Tape Library . . 17 Library, Model S54 .
Page 10 Supported cable distances . . 200 Tape drive configuration for encryption Choosing the port and topology through which your Fibre Channel connection can be made . . 202 IBM System Storage TS3500 Tape Library with ALMS: Introduction and Planning Guide...
Page 11: Read This First
Read this first This is the eighth edition of the IBM System Storage TS3500 Tape Library with ALMS Introduction and Planning Guide (October 2012). This guide is published specifically for the TS3500 Tape Library with the Advanced Library Management System (ALMS).
Page 12: Fourth Edition (September 2009)
First edition (September 2008) The following information was new or changed in the first edition: v Information specific to the TS3500 Tape Library with the Advanced Library Management System (ALMS) v Introduction of the IBM System Storage TS1130 Tape Drives (3592 tape drive...
Page 13: Send Us Your Feedback
Your feedback is important in helping to provide the most accurate and high-quality information. If you have comments or suggestions for improving this publication, you can send us comments by e-mail to starpubs@us.ibm.com or use the readers' comments form at the back of this publication. Be sure to include the...
Page 14 IBM System Storage TS3500 Tape Library with ALMS: Introduction and Planning Guide...
Page 15: Safety And Environmental Notices
Most danger or caution notices contain a reference number (Dxxx or Cxxx). Use the reference number to check the translation in the IBM Systems Safety Notices, G229-9054 manual. The sections that follow define each type of safety notice and give examples.
Page 16: Environmental Notices
Class II laser product The TS3500 Tape Library is a Class II laser product. It is important for you to be aware of the laser caution label. See Figure 1 on page xvii for an example of the label.
Page 17: Class I Laser Product
Class I laser product The TS3500 Tape Library contains a laser assembly that complies with the performance standards set by the U.S. Food and Drug Administration for a Class I laser product.
Page 18 IBM System Storage TS3500 Tape Library with ALMS: Introduction and Planning Guide...
Page 19: About This Publication
About this publication This guide contains information about how to plan for the IBM System Storage TS3500 Tape Library, also known as the 3584 Tape Library. This guide is specific to the TS3500 Tape Library with ALMS. While reading this publication, you are introduced to the TS3500 Tape Library and learn how it interacts in both mainframe and Open Systems environments.
Page 20: Ibm I, System I, And I5/Os Source
Guide. One version of each document is specific to the TS3500 Tape Library with the Advanced Library Management System (ALMS) and provides details about features and functions that are only available for libraries with ALMS installed and enabled. Refer to the titles of each guide in order to determine which version you need.
Page 21 Implementing IBM Tape in Linux and Windows, SG24-6268. This book is available on the Web at http://www.redbooks.ibm.com/redpieces/pdfs/sg246268.pdf. v Implementing IBM Tape in Unix Systems, SG24-6502. This book is available on the Web at http://www.redbooks.ibm.com/redbooks/pdfs/sg246502.pdf. v The IBM TotalStorage Tape Libraries Guide for Open Systems, SG24-5946 v The LTO Ultrium Primer for IBM eServer iSeries Customers, REDP-3580.
Page 22: Authorized Suppliers Of Bar Code Labels
This information is provided for the convenience of TS3500 Tape Library users only, and is not an endorsement or recommendation of such providers. IBM is not responsible for the quality of bar code labels procured from sources other than IBM.
Page 23: Data Storage Values
10%. To reduce the possibility of confusion, the TS3500 Tape Library documentation represents data storage using both decimal and binary units. Data storage values...
Page 24 IBM System Storage TS3500 Tape Library with ALMS: Introduction and Planning Guide...
Page 25: Chapter 1. Introduction
Open Systems environments. Figure 2 on page 2 shows a 6-frame version of the TS3500 Tape Library. An individual library, or library string, consists of one base frame and up to 15 expansion frames and can include up to 192 tape drives and more than 20 000 tape cartridges.
Page 26: The Ts3500 Tape Library
Figure 2. The TS3500 Tape Library The TS3500 Tape Library comes with several tape drive, frame model, and feature options in order to meet your specific needs. Some additional features of the TS3500 Tape Library are listed below: v Ability to attach multiple simultaneous heterogeneous servers...
Page 27: Structure Of The Library
This topic defines base and expansion frames and describes the models of the TS3500 Tape Library. The basic TS3500 Tape Library is a single storage unit known as the base frame (Models L32, L52, or L53 for LTO Ultrium tape drives, or Models L22 or L23 for 3592 tape drives).
Page 28 Models L22, L32, L52, D22, D32, and D52. The models of the TS3500 Tape Library vary depending on the type of media they contain and whether the frame is a service bay, a base frame, or an expansion frame.
Page 29: Ts3500 Tape Library Frame Models
Table 5. TS3500 Tape Library frame models (continued) Frame model Type Depth Media type and capacity Other v Optionally equipped with the enhanced frame control assembly Up to 12 v Optionally equipped with Expansion drives and up backend Fibre Channel switches...
Page 30: Frames In The Ibm System Storage Ts3500 Tape
L53 (base frame) is on the left. A Model D23 or D53 (expansion frame) is on the right and attaches to the base frame. Figure 3. Frames in the IBM System Storage TS3500 Tape Library IBM System Storage TS3500 Tape Library with ALMS: Introduction and Planning Guide...
Page 31: Dual Accessors And Service Bays
This topic describes dual accessors and service bays and how they can enhance library performance. When an optional second accessor is installed, the TS3500 Tape Library features enhanced availability by utilizing an additional accessor. The additional accessor enables the library to operate without disruption if any component of the working accessor fails.
Page 32: Cartridge Slots In The Service Bays Of The Ts3500
Figure 5. Cartridge slots in the service bays of the TS3500 Tape Library If you already have an installed TS3500 Tape Library and you want to add a second accessor, your IBM service representative can add the accessor and its service bays.
Page 33: High Density Technology
83. High density technology The TS3500 Tape Library offers high-density, storage-only frame models (HD frames) designed to greatly increase storage capacity without increasing frame size or required floor space. The new HD frames (Model S24 for 3592 tape cartridges and Model S54 for LTO Ultrium tape cartridges) contain HD storage slots.
Page 34: The Hd Frame (Left) And Top-Down View Of
Use caution when inserting or removing cartridges from HD slots. HD frame model S24 provides storage for up to 1 000 IBM 3592 tape cartridges. HD frame model S54 provides storage for up to 1 320 LTO Ultrium tape cartridges.
Page 35 B). In order to have the expansion frame installed somewhere other than the end of the library string, the IBM service representative must obtain a service contract to uninstall additional frames as necessary to accommodate the customer's request.
Page 36: Components Of The Library
Components of the library This topic describes the major parts of the TS3500 Tape Library. The TS3500 Tape Library consists of the major components shown in Figure 7 on page 14 (the figure depicts Model L53). For a more complete description of each component, see the appropriate sections in the IBM System Storage TS3500 Tape Library with ALMS Operator Guide.
Page 37 6 IBM LTO Ultrium tape drives or 3592 tape drives Mounted in the TS3500 Tape Library, one or more units that read and write data that is stored on tape cartridges. IBM LTO Ultrium tape drives and 3592 tape drives may not be mixed in the same frame. IBM Ultrium tape drives use LTO Ultrium tape cartridges;...
Page 38: Components Of The Ibm System Storage Ts3500 Tape Library
Figure 7. Components of the IBM System Storage TS3500 Tape Library. The front of a Model L53 is shown at the top. The rear of Model L53 is shown on the bottom. IBM System Storage TS3500 Tape Library with ALMS: Introduction and Planning Guide...
Page 39: Structure Of The Shuttle Complex
Structure of the shuttle complex In order to meet the needs of large data center archives that have to store increasing amounts of data, the TS3500 Tape Library offers shuttle technology that enables flexible library growth on a z-axis. This growth flexibility, enabled by shuttle connections between HD libraries, allows a higher maximum capacity for a single library image of multiple TS3500 library strings.
Page 40: Ts3500 Tape Library Shuttle Complex
Shuttle connections attach to shuttle stations that are mounted on HD frames. Logical configuration of the shuttle complex A shuttle complex enables multiple TS3500 Tape Library strings to appear as a single library image to the host. Each library string is still its own SCSI library, however a library manager application such as HPSS, aggregates the multiple SCSI libraries into a single library image.
Page 41: Supported Tape Drives
The LTO Ultrium tape drives and the 3592 tape drives are high-performance, high-capacity data-storage units that can be installed in the TS3500 Tape Library. Up to 12 drives can be installed in each base and expansion frame of the library, but the two types of drives cannot be mixed in the same frame.
Page 42: Lto Ultrium Tape Drives
LTO Ultrium tape drives There are six generations of Linear Tape-Open (LTO) Ultrium tape drives. The newest of these drives, the IBM System Storage TS1060 Tape Drive Model F6A, is a dual-ported drive that facilitates 8 Gbps Fibre Channel connectivity. This drive is also known as the Ultrium 6 tape drive and is differentiated by its machine type and model number 3588 F6A.
Page 43 The Ultrium tape drives can read tapes that have been written by non-IBM Ultrium drives. They also write to tapes that can be read by non-IBM Ultrium drives. All generations of Ultrium tape drives and cartridges can reside in the same frame.
Page 44: 3592 Tape Drives
Model EU6 is discussed. All 3592 tape drives include an RS-422 library interface port for communication with the TS3500 Tape Library. The 3592 tape drives use the Statistical Analysis and Reporting System to isolate failures between media and hardware. The TS1130 and...
Page 45 The 3592 tape drives provide the following performance, capacity, and availability features: N+1 power supplies When installed in the TS3500 Tape Library frame, this helps to increase drive availability in the event of a power failure. Media reuse The 3592 tape drives can reuse different types of tape and multiple densities (logical formats) across various drive generations.
Page 46 SCSI Mode Sense command and specifying Mode Page X'23'. Capacity scaling is only offered on the JA, JB, and JC media types. For the exact Mode Select commands and settings necessary to invoke scaling, refer to the IBM System Storage TS3500 Tape Library SCSI Reference. WORM The 3592 tape drives support write-once-read-many (WORM) behaviors and format attributes.
Page 47 TS1130, and TS1140 tape drives), and JY Advanced WORM cartridge (for TS1140 tape drives). WORM cartridges are factory-formatted as WORM cartridges and may not be converted to data cartridges. The 3592 tape drives allow append operations to data already on WORM cartridges, but do not allow data to be overwritten under any circumstances.
Page 48 Firmware for each model of 3592 tape drive (TS1140, TS1130, TS1120, or J1A) only works in that specific model. The 3592 tape drive supports four types of the IBM 3592 Tape Cartridge. For more information about the supported cartridges, see “Mixing media in drives” on page...
Page 49: Supported Tape Cartridges
Note: Management and handling of media cartridges is a customer function and responsibility. In the TS3500 Tape Library, frames that are installed with Ultrium tape drives use Ultrium tape cartridges. Frames that are installed with 3592 tape drives use 3592 tape cartridges.
Page 50: Compatible Servers And Software
This section identifies ways to determine the servers and software that support the TS3500 Tape Library. The TS3500 Tape Library is supported by a wide variety of servers, operating systems, and adapters. These attachments can change throughout the life cycle of the product.
Page 51 IBM sales representative, IBM business partner, or an independent software provider. 2. If you attach your library to a non-IBM platform with non-IBM software, it is recommended that you contact your software vendor to obtain a matrix of compatible hardware, software, firmware revisions, and adapter cards.
Page 52: Supported Device Drivers
For a complete description of the mtlib program and command syntax, see the IBM Tape Device Drivers Installation and User's Guide. The IBM Tape Device Drivers Installation and User's Guide can be found on the web: http://www-01.ibm.com/support/docview.wss?rs=577&uid=ssg1S7002972 . Using TSLM for communication This topic describes the IBM Tape System Library Manager (TSLM).
Page 53 – Emulation of an IBM 3494 library on top of an attached TS3500 library For more information about TSLM, refer to the IBM Tape System Library Manager User’s Guide (GA32-2208). Chapter 1. Introduction...
Page 54: Attachment Interfaces
8.20.0.x or higher. v Through a 3592-C07 Tape Controller with integrated library manager, then to the TS3500 Tape Library with frame model L23 or D23 equipped with 8 Gb Fibre Channel switches (feature code 4875 or 4877) These configurations provide the interconnection to the TS3500 Tape Library.
Page 55: Fibre Channel Interface
This section sets forth the conditions that apply to drives in the TS3500 Tape Library that use a Small Computer System Interface (SCSI) interface. The TS3500 Tape Library operates as a set of SCSI-3 devices. For drives that use a SCSI interface, the following conditions apply:...
Page 56: Ficon And Escon Interfaces
(81 ft) with the appropriate cable and terminator for HVD devices and up to 12 m (39 ft) for LVD devices. For more information about the SCSI interface, see the IBM System Storage TS3500 Tape Library SCSI Reference. FICON and ESCON interfaces This section describes the FICON and ESCON interfaces used to attach the TS3500 Tape Library to the System z server.
Page 57 TS3500 Tape Library. For additional information about attaching the IBM System z server to the TS3500 Tape Library through the 3953 Tape System, see the IBM 3953 Tape System Introduction and Planning Guide. For additional information about...
Page 58: Mixing Drives In Frames
RS-422 RS-422 Drives Figure 9. Attaching the TS3500 Tape Library to the System z server (mainframe host) Mixing drives in frames This section contains a matrix of the drives that are compatible in a physical frame (model) of the TS3500 Tape Library.
Page 59: Mixing Drives In A Logical Library
Note: If you plan to use encryption, also refer to “Configuration prerequisites for encryption” on page 219. The TS3500 Tape Library supports a mixture of Ultrium drive types in a logical library, but it does not support a mixture of Ultrium and 3592 tape drives in a logical library.
Page 60: Library
Library 2 Drive Windows Drive Ultrium 3 Tape Logical Drives only Library 3 Drive pSeries Figure 10. Examples of methods for mixing Ultrium drive types in a logical library IBM System Storage TS3500 Tape Library with ALMS: Introduction and Planning Guide...
Page 61: Mixing Media In Drives
This section contains information about compatible media and drives in the TS3500 Tape Library. Not all cartridges that are supported by the TS3500 Tape Library are compatible with all drives. Ultrium cartridges are not supported by 3592 tape drives, and 3592 tape cartridges are not supported by Ultrium drives.
Page 62: Cartridges That Are Compatible With 3592 Tape
E07) EFMT4 (E07) supported supported supported supported supported JC, JY , JK EEFMT3 (encrypted Reformat supported supported supported supported supported E06) EFMT3 (E06) supported supported supported supported supported IBM System Storage TS3500 Tape Library with ALMS: Introduction and Planning Guide...
Page 63 Table 12. Cartridges that are compatible with 3592 tape drives (continued) EEFMT3 (encrypted Reformat Reformat Reformat Reformat supported E06) EFMT3 Reformat Reformat (E06) supported JB, JX EEFMT2 (encrypted Read only Reformat Reformat Reformat supported E05) EFMT2 Read only Read only (E05) supported EEFMT3...
Page 64: Multi-Path Architecture
Small computer system interface (SCSI) v Fibre channel The Multi-Path Architecture of the TS3500 Tape Library is designed to provide the capability to share the library robotics. This is accomplished by partitioning the library into as many as 192 logical libraries (up to the number of drives installed), and providing each logical library its own separate and distinct drive(s), storage slots, and control paths.
Page 65: Library Sharing
Library sharing This section describes ways that you can configure the TS3500 Tape Library into one or more logical libraries that can be shared by multiple applications. The default configuration for the TS3500 Tape Library allows a single application to operate the library through a single control path. Often, however, it is advantageous to be able to share a single library between heterogeneous or homogeneous applications.
Page 66: Examples Of Configurations For Sharing An Ibm
Figure 11. Examples of configurations for sharing an IBM System Storage TS3500 Tape Library. Lines from one or more drives to the library controller represent control paths. IBM System Storage TS3500 Tape Library with ALMS: Introduction and Planning Guide...
Page 67: Using Multiple Logical Libraries
A LUN is a number used by a server to identify a drive. In a TS3500 Tape Library with ALMS, a logical library can share the tape drives and storage slots of another logical library. The library also shares the I/O slots and the cartridge accessor on a first-come, first-served basis.
Page 68: Using Multiple Control Paths
IBM recommends that you disable RSM to use this feature. To add or remove additional control paths, see the IBM System Storage TS3500 Tape Library with ALMS Operator Guide. The sections that follow describe two potential uses for multiple control paths.
Page 69: Advanced Library Management System
Using multiple control paths for control path failover The TS3500 Tape Library offers an optional control path failover feature that enables the host device driver to resend the command to an alternate control path for the same logical library.
Page 70: Dynamic Partitioning
For information about migrating to dynamic partitioning and manually assigning cartridges to a logical library, refer to the IBM System Storage TS3500 Tape Library with ALMS Operator Guide. The primary and backup copies of VOLSER assignment and physical location of cartridges are stored in non-volatile random access memory (NVRAM).
Page 71: Transparent Addition Or Removal Of Storage Capacity
This topic describes the virtual input/output (I/O) slots feature and its benefits in a library with the Advanced Library Management System (ALMS). When ALMS is enabled in a TS3500 Tape Library, virtual I/O slots are enabled by default so that the library automatically queues all cartridge moves between the I/O station and the storage slots.
Page 72: Cartridge Assignment Policy
When an unassigned cartridge is present in the I/O station, the library reads its VOLSER label and automatically assigns it to the logical library that is specified in the range of VOLSERs which was previously selected by the system administrator IBM System Storage TS3500 Tape Library with ALMS: Introduction and Planning Guide...
Page 73: Insert Notification Setting
Insert notification setting This section describes insert notification. This is an optional setting that enables the TS3500 Tape Library to monitor the I/O station for new media that does not have a logical library assignment. Note: Insert notification is no longer recommended and is not supported in any library that includes an HD frame.
Page 74: Power Structure Of The Ts3500 Tape Library
Storage TS3500 Tape Library with ALMS Operator Guide. Power structure of the TS3500 Tape Library This section introduces the two power structures that are offered by the TS3500 Tape Library. Depending on the frames that you have, the library offers two power structures:...
Page 75: Enhanced Frame Control Assembly
Fibre Channel Ultrium and 3592 tape drives offer path failover and load balancing capabilities that enable the IBM device driver to resend a command to an alternate path. The alternate path can include another host bus adapter (HBA), Storage Area Network (SAN), or library control path drive.
Page 76 Dynamic load balancing uses all HBAs whenever possible and balances the load between them to optimize the resources in the machine. Both CPF and DPF require the use of the IBM device driver, and are supported exclusively with products that bear the IBM logo on the operating systems indicated in Table 13.
Page 77: Expanded I/O Capacity
I/O station that will accept Ultrium tape cartridges). The TS3500 Tape Library also supports an option for 64 additional I/O slots in a newly purchased Model D23 or D53 frame. A D-frame with I/O installed includes four independently accessible I/O stations.
Page 78: Increasing Capacity
The Capacity Expansion feature (feature code 1603) is a license key that lets you enable the storage slots inside the front door of Model L32 of the TS3500 Tape Library. With the Capacity Expansion feature installed, the library offers 140 additional slots for Ultrium tape cartridges in the Model L32 if the second I/O station is not present and 88 additional slots if the second I/O station is present.
Page 79: Intermediate, Full, And Capacity On Demand Features For Models L22, L23, L52, And L53
Intermediate, Full, and Capacity On Demand features for Models L22, L23, L52, and L53 In the TS3500 Tape Library, the initial (entry) capacity of a Model L22 or Model L23 frame is enabled to use 58 cartridge slots for 3592 tape cartridges. If you add...
Page 80: Web Interface
Specialist, the Web interface for the TS3500 Tape Library. The Tape Library Specialist Web interface enables operators and administrators of the TS3500 Tape Library to manage storage devices from any location in an enterprise. The Tape Library Specialist allows you to communicate directly with your library and perform a full range of end user, operator, and administrator tasks without being at the operator panel.
Page 81: Ts3500 Tape Library Command Line Interface
For more information about using the Tape Library Specialist Web interface, see the section about operating the library from the Web in the IBM System Storage TS3500 Tape Library with ALMS Operator Guide. TS3500 Tape Library Command Line Interface This topic describes the TS3500 Tape Library Command Line Interface (CLI) program, which provides the ability to access TS3500 Tape Library functions through a CLI.
Page 82: Remote Support
(such as configuration, library and drive code versions, and error logs) to IBM. The Call Home feature of the TS3500 Tape Library has three different, but related, capabilities: Problem Call Home, Heartbeat Call Home, and Test Call Home. The TS3500 Tape Library sends data files that may be helpful to Support Center personnel for all three types of Call Home.
Page 83: Remote Support Through A Modem
Problem Call Home The TS3500 Tape Library or one of its drives detects a problem and the library performs a Call Home operation to create a Problem Management Record (PMR) in the IBM Remote Technical Assistance Information Network (RETAIN).
Page 84: Remote Support Through A System Console
Engine, are connected to a System z server (mainframe host). The TS3000 System Console (TSSC) provides the same functionality to attach a TS3500 Tape Library that is connected to an Open Systems server. The TSSC is a personal computer (PC), complete with an Ethernet port. A customer rack-mountable version of the TS3000 System Console is available by ordering feature code 2732.
Page 85: For Remote Support
The library feature code 9217 provides an Ethernet cable for the remote support connection from the TS3500 Tape Library to a system console. Figure 13 on page 62 shows the attachment of a system console to the TS3500 Tape Library for remote support. (Refer to Table 17 on page 62.)
Page 86: Remote Support System Console Connection
Note: All of the listed capabilities do not apply to every product type. For example, the TS3500 Tape Library does not utilize wellness checking, daily log file storage, or code image broadcast. IBM System Storage TS3500 Tape Library with ALMS: Introduction and Planning Guide...
Page 87: Remote Support Security
Complete information on how to configure the TSSC for ECC Call Home is in the IBM TS3000 System Console Maintenance Information publication. Remote support security This section describes the security design for remote support for the TS3500 Tape Library through a system console. The TS3000 System Console (TSSC) provides Ethernet connectivity to all attached systems through a private internal network.
Page 88: Attachment Of The System Console To The Ts3500 Tape Library And The 3953 Tape System
CE - The TS3500 calls home through either the TSSC or the modem but not both. Figure 14. Attachment of the system console to the TS3500 Tape Library and the 3953 Tape System for remote support Dial Out security features...
Page 89 5. The default setting for the call home feature is enabled. The Call Home feature may be disabled by an IBM Service Representative. None of the customer data stored on the tape or in memory for the TS3500 Tape Library is transmitted or accessed in a Call Home session. Call Home is enabled or disabled by a CETool menu selection.
Page 90: Port Information For Firewall Environments
Security for Encryption Support Encryption support in the TS3500 Tape Library and 3592 tape controllers (models C07, C06 and J70) allow system-managed tape encryption on IBM System z platforms. An IBM service representative installs routers between the internal LAN network, which is connected to the controllers, and the customer's LAN network.
Page 91: External Communication Connections To The Ts3500 Tape Library Control System
Remote support security for the TS3500 Tape Library through a system console This section describes remote support security for the TS3500 Tape Library through a system console. Figure 15 illustrates all of the external communication connections to the TS3500 Tape Library control system.
Page 92 Tape Library Specialist Web interface also provides an option to authenticate through the Storage Authentication Service (SAS). See the section about Web security in the IBM System Storage TS3500 Tape Library with ALMS Operator Guide.
Page 93: Methods Of Cleaning Drives
Automatic cleaning is always enabled with the Advanced Library Management System (ALMS). The head of every tape drive in the TS3500 Tape Library must be kept clean to prevent errors caused by contamination. To help you keep the drives clean, IBM provides a cleaning cartridge with the library.
Page 94: Snmp Messaging
SNMP messaging This section describes the Simple Network Management Protocol (SNMP), which allows the TS3500 Tape Library to send alerts over a LAN network to a monitoring server. Occasionally, the TS3500 Tape Library may encounter a situation that you want to know about.
Page 95: Snmp Audit Logging
Figure 16. The SNMP messaging system For information about interpreting an SNMP trap or using SNMP MIBs to monitor your library, see the appropriate sections in the IBM System Storage TS3500 Tape Library Operator Guide. For information about SNMP audit logging, refer to “SNMP audit logging.”...
Page 96: Smi-S Support
This interface uses an object-oriented, XML-based, messaging-based protocol designed to support the specific requirements of managing devices such as the TS3500 Tape Library in a storage environment. The SMI-S specification describes the information available to a WBEM client, such as the IBM Tivoli Storage Productivity Center (TPC), from an SMI-S-compliant CIM WBEM Server such as the TS3500 Tape Library.
Page 97: Required Upgrade For Those Frames Providing Ethernet Attachment To The Smi-S Agent
IP address on port 5988 by default. The SMI-S service agent can be enabled and disabled using the library Web interface (see the appropriate section in the IBM System Storage TS3500 Tape Library with ALMS Operator Guide). The TS3500 Tape Library embedded SMI-S service uses "root/ibm" as the Namespace.
Page 98: Secure Socket Layer (Ssl) Functionality
The LDAP or AD server then authenticates the user's ID and password; if they are valid then one or more user groups are assigned. The TS3500 Tape Library then assigns the user a role based on the LDAP or AD group.
Page 99: Storage Authentication Service Overview
TS3500 Tape Library Specialist Web interface when SAS is enabled. v The maximum length of a Group is 15 characters. Groups exceeding 15 characters in length will not map to a defined role in the TS3500 Tape Library. Chapter 1. Introduction...
Page 100: Ipv6 Functionality
LDAP group in the list must have the same name as a role that is defined in the TS3500 Tape Library. The first LDAP group to match a role determines the role of the user. Avoid ambiguity of multiple matches by making sure that only one group matches a role in the TS3500 Tape Library.
Page 101 An IPv6 (Normal) address has the following format: y : y : y : y : y : y : y : y where y is called a segment and can be any hexadecimal value between 0 and FFFF. The segments are separated by colons - not periods. An IPv6 normal address must have eight segments, however a short form notation can be used in the Tape Library Specialist Web interface for segments that are zero, or those that have leading zeros.
Page 102 IP address, or the prefix. The non-bold portion is called the host portion of the IP address, since it identifies an individual host on the network. IBM System Storage TS3500 Tape Library with ALMS: Introduction and Planning Guide...
Page 103: Drive Performance
Drive performance This topic gives performance data for Ultrium and 3592 tape drives. Table 22 provides drive performance of the Ultrium tape drives with different media. Table 23 on page 80 provides drive performance of the 3592 tape drives. Table 24 on page 81 provides additional information for 3592 media. Table 22.
Page 104: Performance Specifications Of The 3592 Tape
18 seconds (20% scaled JA) 18 seconds (20% Not supported scaled JA) 24 seconds (20% scaled JB) Not supported 26 seconds (20% Not supported Not supported Not supported scaled JC) IBM System Storage TS3500 Tape Library with ALMS: Introduction and Planning Guide...
Page 105: Average Block Locate Time From Load Point For 3592 Tape Cartridge In 3592 Tape Drives
Table 23. Performance specifications of the 3592 tape drives (continued) 29 seconds (100% 35 seconds (100% Not supported Not supported scaled JA) scaled JA) 47 seconds (100% 38 seconds (100% scaled JB) Not supported scaled JB) Average rewind time 42 seconds (100% Not supported Not supported Not supported...
Page 106 (EFMT1 300 GB [279.39 GiB]; EFMT2 and Not supported 28 seconds 33 seconds 40 seconds EEFMT2 500 GB [465.66 GiB]; EFMT3 and EEFMT3 640 GB [596.04 GiB]) IBM System Storage TS3500 Tape Library with ALMS: Introduction and Planning Guide...
Page 107: Library Performance
For maximum performance with SCSI drives, multiple SCSI buses may be required and the TS3500 Tape Library devices must be the only target devices that are active on each SCSI bus. For more information, see the section about the SCSI interface in the IBM System Storage TS3500 Tape Library with ALMS Operator Guide.
Page 108: Inventory Times
Close the front door after manually accessing the inventory Note: The TS3500 Tape Library tracks the logical location of all of its elements by performing an automatic inventory as required (if you issue the SCSI Initialize Element Status command, it is allowed but ignored). The automatic inventory improves application performance.
Page 109: Mount Performance And Cartridge Move Time
Table 25 shows the mount performance and average move time for a TS3500 Tape Library without dual accessors and without HD frames. Table 25. Mount performance and move time for drives in a TS3500 Tape Library without dual accessors and without HD frames...
Page 110: Import And Export Performance With Virtual I/O Slots
Library with dual active accessors and virtual I/O slots enabled, but without HD frames. Table 27. Specifications for imports per hour and average I/O station drain time for a TS3500 Tape Library using one active accessor I/O station in frame 1...
Page 111: Hd Frame Performance Considerations
Table 27. Specifications for imports per hour and average I/O station drain time for a TS3500 Tape Library using one active accessor (continued) Notes: 1. The following library setup was used to obtain the stated performance data: v ALMS and virtual I/O slots are enabled...
Page 112: Shuttle Complex Performance Considerations
Cartridge eject operations prior to mount operations reduce the need to destage LRU cartridges (this is because eject operations empty some Tier 0 slots) Eject and insert performance can also be impacted for a TS3500 Tape Library that includes HD frames. The impact to eject performance is determined by factors similar to mount performance (distribution of tiers from which cartridges are ejected).
Page 113 full in the home logical library. In addition, the application can further maximize performance in a shuttle complex by supporting a "floating home library" algorithm so that cartridges make one-way trips rather than round trips across shuttle connections. However, a "floating home library" algorithm increases the need for customer monitoring for an imbalance of cartridges across libraries that can lead to a full, or nearly full, capacity utilization of a library string.
Page 114 IBM System Storage TS3500 Tape Library with ALMS: Introduction and Planning Guide...
Page 115: Chapter 2. Physical Planning Specifications
Library and also provides planning considerations for a TS3500 Tape Library shuttle complex. For optimum operation of the TS3500 Tape Library, make sure that you place it in an environment that meets the requirements described in the following sections. For proper performance in a TS3500 Tape Library shuttle complex, also review and understand the physical requirements for this configuration.
Page 116: Physical Specifications For Models L22 And D22
Physical specifications for Models L22 and D22 This section gives physical specifications (such as height, width, depth, and weight) of Models L22 and D22 of the TS3500 Tape Library. Table 29. Physical characteristics of the TS3500 Tape Library, Models L22 and D22 Physical Characteristic Measurement Height of L22 and D22 frames (on casters) 1800 mm (70.9 in.)
Page 117: Physical Specifications For Models L23 And D23
Physical specifications for Models L23 and D23 This section gives physical specifications (such as height, width, depth, and weight) of Models L23 and D23 of the TS3500 Tape Library. Table 30. Physical characteristics of the TS3500 Tape Library, Models L23 and D23 Physical Characteristic Measurement Height of L23 and D23 frames (on casters) 1800 mm (70.9 in.)
Page 118: Physical Specifications For Models L32 And D32
Physical specifications for Models L32 and D32 This section gives physical specifications (such as height, width, depth, and weight) of Models L32 and D32 of the TS3500 Tape Library. Table 31. Physical characteristics of the TS3500 Tape Library, Models L32 and D32 Physical Characteristic Measurement Height of L32 and D32 frames (on casters) 1800 mm (70.9 in.)
Page 119: Physical Specifications For Models L52 And D52
Physical specifications for Models L52 and D52 This section gives physical specifications (such as height, width, depth, and weight) of Models L52 and D52 of the TS3500 Tape Library. Table 32. Physical characteristics of the TS3500 Tape Library, Models L52 and D52 Physical Characteristic Measurement Height of L52 and D52 frames (on casters) 1800 mm (70.9 in.)
Page 120: Physical Specifications For Models L53 And D53
Physical specifications for Models L53 and D53 This section gives physical specifications (such as height, width, depth, and weight) of Models L53 and D53 of the TS3500 Tape Library. Table 33. Physical characteristics of the TS3500 Tape Library, Models L53 and D53 Physical Characteristic Measurement Height of L53 and D53 frames (on casters) 1800 mm (70.9 in.)
Page 121: Physical Specifications For Ha1 Frame
This section gives the height, width, depth, and weight of the HA1 frame of the TS3500 Tape Library. If your TS3500 Tape Library contains a second accessor, the following are the physical specifications for the HA1 frame (service bay A).
Page 122: Physical Specifications For Model S24
The actual weight of the library varies, depending on the configuration and cartridge capacity. 3. One shuttle station can optionally be mounted on a Model S24 frame in a TS3500 Tape Library shuttle complex. IBM System Storage TS3500 Tape Library with ALMS: Introduction and Planning Guide...
Page 123: Physical Specifications For Model S54
The actual weight of the library varies, depending on the configuration and cartridge capacity. 3. One shuttle station can optionally be mounted on a Model S54 frame in a TS3500 Tape Library shuttle complex. Chapter 2. Physical planning specifications...
Page 124: Floor Requirements
Maximum out-of-level condition must not exceed 40 mm (1.6 in.) over the entire length and width of the library. The floor on which the TS3500 Tape Library is installed must be able to support: v Up to 4.8 kilograms per square centimeter (68.6 pounds per square inch) of point loads exerted by the leveling jackscrews v Up to 211 kilograms per square meter (43.4 pounds per square foot) of overall...
Page 125: Delivery Route
Delivery route This section defines the conditions of the route by which the TS3500 Tape Library will be delivered. Check the delivery route that the library must travel from your loading dock to the installation location. Ensure that the library will fit through all doors, hallways, and elevators.
Page 126: Security
Move restraints This section discusses the location of points on the TS3500 Tape Library that you can use to restrain the unit from potential movement (such as an earthquake). Should you want to restrain the TS3500 Tape Library from potential movement (for example, from earthquake), restraining points are located at the bottom of the unit (see 1 in Figure 18 on page 103).
Page 127: Clearance Specifications For The Library
This section helps you to calculate the length of a TS3500 Tape Library and the clearances for service. Table 37 on page 104 shows the length of the TS3500 Tape Library both with and without service bays and including side clearances; Figure 19 on page 105 shows the location of the clearances for Models L22, D22, L23, D23, L52, D52, L53, D53, S24, S54, and the service bays.
Page 128: Clearance Requirements For The Ts3500 Tape
Table 37. Clearance requirements for the TS3500 Tape Library. The table gives the clearances for a library both with and without service bays. Length of A in Figure 19 on Length of A in Figure 19 on page 105 or in Figure 20 on...
Page 129: Size Of Operator And Service Clearances For The Ibm System Storage Ts3500 Tape Library
Move restraints Figure 19. Size of operator and service clearances for the IBM System Storage TS3500 Tape Library, Models L22, D22, L23, D23, L52, D52, L53, D53, S24, S54, and the service bays. The top measurements are in millimeters; the bottom measurements are in inches.
Page 130: Size Of Operator And Service Clearances For The Ibm System Storage Ts3500 Tape Library
Operator side Move restraints Figure 20. Size of operator and service clearances for the IBM System Storage TS3500 Tape Library, Models L32 and D32. The top measurements are in millimeters; the bottom measurements are in inches. The service clearance area (and operator clearance area at the front of both frames) is denoted by dotted lines.
Page 131: Clearance Specifications For The Shuttle Complex
Clearance specifications for the shuttle complex This topic provides dimensions of a TS3500 Tape Library shuttle complex and helps you to calculate the required clearances for access and service. The clearance specifications for a TS3500 Tape Library shuttle complex vary depending on the selected configuration.
Page 132: Routing Fibre Channel Cables Through The Top Of A Frame
As an alternative to routing Fibre Channel cables from servers to the bulkhead at the bottom rear of the TS3500 Tape Library, you can route the cables through the top of the library frame (see 1 in Figure 22 on page 109).
Page 133: Opening For Routing Fibre Channel Cables From Servers Through The Top Of A Frame
Figure 22. Opening for routing Fibre Channel cables from servers through the top of a frame To route the cables through the top of a frame, perform the following procedure. 1. Open the cable access door at the top of the frame (see 1 in Figure 23). Figure 23.
Page 134: Positioning The Fibre Channel Cable Inside The Frame
Figure 25. Positioning the Fibre Channel cable outside the frame 8. Carefully close the cable access door. Padding on the door holds the cables in place safely and securely. IBM System Storage TS3500 Tape Library with ALMS: Introduction and Planning Guide...
Page 135: Routing Cables Through The Top For Installations On A Solid Floor
This section describes the features of frame models L23 and D23 to be used for a fire suppression system. Each L32 or D32 frame in the TS3500 Tape Library has an allowable area on the top that may be cut to allow entrance of pipes, conduits, or other parts (see 1 in Figure 26 on page 112).
Page 136: Fire Suppression For All Other Models
This section describes the tape library frame features provided for a fire suppression system. Each L22, D22, L23, D23, L52, D52, L53, D53, and HA1 frame in the TS3500 Tape Library has an allowable area on the top that may be cut to allow entrance of pipes, conduits, or other parts (see 1 in Figure 27 on page 113).
Page 137: Allowable Area For Mounting Fire-Suppression Equipment (Top View Of Models L22, D22, L23, D23, L52, D52, L53, D53, S24, S54, Or The Ha1 Frame)
REAR 504.7 504.7 19.9 19.9 14.2 14.2 FRONT Figure 27. Allowable area for mounting fire-suppression equipment (top view of Models L22, D22, L23, D23, L52, D52, L53, D53, S24, S54, or the HA1 frame) Chapter 2. Physical planning specifications...
Page 138: Running Cables, Wiring, And Pipes Between Frames
Figure 28 shows a side view of the area available to run cables, wiring, and pipes between frames of the TS3500 Tape Library. The area is a triangular section that is 81 mm (3.2 in.) wide by 140 mm (5.5 in.) long (see 1 in Figure 28). Your fire-suppression mechanical equipment must fit within the allowable area or be installed outside the library.
Page 139: Environmental Specifications
Environmental specifications This section provides the environmental specifications for the TS3500 Tape Library. The TS3500 Tape Library is compliant with the environmental guidelines set by the American Society of Heating, Refrigerating and Air-Conditioning Engineers, Inc. (ASHRAE). The information in Table 38 is excerpted from Thermal Guidelines for Data Processing Environments, published in 2004 by ASHRAE.
Page 140: Acoustical Specifications
When the library is operating, the cartridge accessor loads, unloads, or moves tape cartridges; when the library is idling, the accessor does not move. The TS3500 Tape Library is a Category 1 product as defined in C-S 1-1710-006. IBM System Storage TS3500 Tape Library with ALMS: Introduction and Planning Guide...
Page 141: Acoustical Specifications For Models L32 And D32
Note: No additional noise is created by adding frame models HA1, S24, or S54. Table 41. Noise emission values for the IBM System Storage TS3500 Tape Library, Models L22, D22, L52, and D52 filled with Ultrium tape drives or 3592 tape drives...
Page 142: Power And Cooling Requirements
This section introduces the power and cooling specifications for the two power structures that are used by TS3500 Tape Library frames. Power and cooling for components of the TS3500 Tape Library are provided by the frame in which they are housed. The two power structures are the frame control...
Page 143: Power And Cooling Specifications For Models L23, D23, L53, And D53
D53 This section gives an overview of the power and cooling requirements of Models L23, D23, L53, and D53 of the TS3500 Tape Library. For Models L23, D23, L53, and D53, each base frame and expansion frame that contains drives has its own enhanced frame control assembly. The enhanced frame...
Page 144: Power Requirements For Frames
Power requirements for frames This topic describes the power requirements for frames in the TS3500 Tape Library. Table 43 lists the electrical characteristics for the TS3500 Tape Library frame models. Table 43. Electrical characteristics of the IBM System Storage TS3500 Tape Library frame...
Page 145 Table 44. Power consumption of TS3500 Tape Library frame models, power consuming features, and drive canisters (continued) FC 1950 PDU FC 4872 TS7700 backend 4 Gb switches (2x) FC 4875 TS7700 backend 8 Gb switches (2x) Tape Drives TS1120 (3592 Models...
Page 146: Sample Calculation Of Total Library Power
1000. Table 45 provides a sample calculation of total power and cooling requirements for a TS3500 Tape Library configuration consisting of one L23 with ten TS1130 tape drives and mounting kits, four D23 models each containing six TS1130 tape drives and mounting kits, one D23 with no drives or enhanced FCA feature (FC 1451), two S24 models, and one HA1 model.
Page 147: Power Requirements For Remote Support Features
Power requirements for remote support features This section describes the power requirements for the remote support features of the TS3500 Tape Library. Table 46 lists the power requirements for the devices that comprise remote support. Table 46. Power requirements for remote support features...
Page 148: Power Cords For Models L32 And D32
This section describes the power cords used with models L32 and D32 of the TS3500 Tape Library. The appropriate power cord for the TS3500 Tape Library is attached at the factory (based on the destination code of your country or region). Chicago, Illinois (U.S.A.) requires a 1.8 m (6 ft) power cord (feature code 9986).
Page 149: Specifications For 200-240 V Ac Power Cord Used With The Ibm System Storage Ts3500 Tape Library, Models L32 And D32
Current: see Table 47 v Phases: 1 v Wires: 3 Table 47. Specifications for 200–240 V ac power cord used with the IBM System Storage TS3500 Tape Library, Models L32 and D32 Dual AC Line Cords 15 A Service Rating...
Page 150: Types Of Receptacles For Power Cords Used By
Phases: 1 v Wires: 3 Table 48. Specifications for 100–127 V ac power cords used with the TS3500 Tape Library, models L32 and D32 Dual ac line cords 20 A service rating Single branch circuit 20 A service rating...
Page 151: Power Cords For Models L22, D22, L52, And D52
Refer to Figure 30 on page 128 and match the number that is beside each receptacle to the receptacle number listed in the table. Table 49. Specifications for power cords used with the IBM System Storage TS3500 Tape Library, Models L22, D22, L52, and D22...
Page 152: Power Cords For Models L23, D23, L53, And D53
Figure 30. Types of receptacles for power cords used by Models L22, D22, L52, and D52 of the TS3500 Tape Library Power cords for Models L23, D23, L53, and D53 This topic describes the power cords used with models L23, D23, L53, and D53 of the TS3500 Tape Library.
Page 153 Table 50. Specifications for power cords used with the IBM System Storage TS3500 Tape Library, Models L23, D23, L53, and D53 (continued) Part Number Length and Type of Power Cord and Feature Type of Service Receptacle Code Dual 4.3 m (14 ft.) non-watertight, 250 V ac, 10 A, GB 2099.1, 1002.
Page 154: Types Of Receptacles For Models L23, D23, L53, And D53 Of The Ts3500 Tape Library
Table 50. Specifications for power cords used with the IBM System Storage TS3500 Tape Library, Models L23, D23, L53, and D53 (continued) Part Number Length and Type of Power Cord and Feature Type of Service Receptacle Code Dual 4.3 m (14 ft.) power cords, unterminated (without a power plug), 200–240 V ac single...
Page 155: Fc 9989 Cable Positions
plugging the cords into the spare outlets on the FC 1950 PDUs. Figure 32 shows the first adjacent frame cord plugging into the upper PDU receptacles and the second adjacent frame power cord plugging into the lower PDU receptacles. The adjacent frames that receive power through FC 9989 can be up to three frames away from the frame with FC 1950.
Page 156 IBM System Storage TS3500 Tape Library with ALMS: Introduction and Planning Guide...
Page 157: Chapter 3. Standard Features Of The Library
This section introduces a pictorial representation of the elements of the TS3500 Tape Library and the feature codes for those elements. When ordering the TS3500 Tape Library, you can use feature codes to perform the following actions: v Specify plant or field installation of tape drives...
Page 158: Elements In The Library
Elements in the library This section provides a flowchart of the elements that are available for a TS3500 Tape Library. Figure 33 shows the elements in the TS3500 Tape Library. Depending on the model of the library, different features are available.
Page 159: Feature Codes For Elements In The Library
Feature codes for elements in the library This topic describes the feature codes for the TS3500 Tape Library and indicates to which model each feature applies and whether or not the feature can be installed by the customer. A customer-setup unit (CSU) is a feature that you, as the customer, can install when the feature is ordered as a field upgrade.
Page 160 Table 51. Feature codes for the models of the TS3500 Tape Library (continued) Feature Code Model Description 1620 Add D32 to existing L22, D22, L23, D23, L52, D52, L53, D53, S24, or S54 Prerequisite: FC 9002 or 9003 1643 L22, L23, L52, L53...
Page 161 Table 51. Feature codes for the models of the TS3500 Tape Library (continued) Feature Code Model Description 1695 LTO test hardware for high density frames (This feature is required if any HD frame is installed on a High Availability subsystem with an L32, L52, or L53 base frame.)
Page 162 Table 51. Feature codes for the models of the TS3500 Tape Library (continued) Feature Code Model Description 2305 D22, D52, D23, D53 Accessor refresh with enhanced grippers and pivot for HA (This field-only feature applies to models with FC 1440.)
Page 163 Table 51. Feature codes for the models of the TS3500 Tape Library (continued) Feature Code Model Description 4875 L23, D23 8 Gb Fibre Channel switch (One switch is provided per feature. The TS7700 requires two switches per frame. The customer must specify FC 4875 or FC 4877.)
Page 164 Table 51. Feature codes for the models of the TS3500 Tape Library (continued) Feature Code Model Description 9205 L23, L53 Enhanced grippers and pivot 9206 D23, D53, S24, S54 Enhanced grippers and pivot for HA 9210 L22, L23, L32, L52, L53...
Page 165 Table 51. Feature codes for the models of the TS3500 Tape Library (continued) Feature Code Model Description | | | | 9698 L32, D32, L52, D52, L53, D53 3588 F6A tape drive customer field install (see feature code 1678) Prerequisites: FC 1700 on Lx2 models, FC 1702...
Page 166 Table 51. Feature codes for the models of the TS3500 Tape Library (continued) Feature Code Model Description 9977 L23, D23, L53, D53 Dual power cords, non-watertight, 4.3 m (14 ft.), 250 V ac, 15 A, with Earth Pin InMetro NBR 14136 plug.
Page 167 This requirement does not apply to a library that contains dual accessors. 11. Must be added to any IBM System Storage TS3500 Tape Library that comes from the plant and has 15 to 16 frames (14 or 15 Model D22, 32, or 52 expansion frames attached to the Model L22, 32, or 52).
Page 168 Feature code 1453 was withdrawn from marketing in December 2008. v Feature codes 2714, 2732, and 2733 were withdrawn from marketing in July 2012. v Feature code 4872 was withdrawn from marketing in August 2011. IBM System Storage TS3500 Tape Library with ALMS: Introduction and Planning Guide...
Page 169: Chapter 4. Using Ultrium Media
Overview of Ultrium Media This section describes Ultrium media. Within the TS3500 Tape Library and subject to certain restrictions, the Ultrium tape drives use the following cartridge types: v IBM System Storage 2500 GB LTO Data Cartridge (Ultrium 6 cartridge without...
Page 170: Lto Worm Cartridge Capacities
The IBM System Storage LTO WORM Data Cartridge is only for use on Ultrium 3 and later tape drives with WORM capable-microcode. The cartridge is designed for applications such as archiving and data retention, and is also suitable for applications that require an audit trail.
Page 171: Ultrium Data Cartridge
This section describes the capacity, construction, operation, and components of the IBM LTO Ultrium Data Cartridge. The IBM Ultrium 6 cartridge is is black with a silkscreen label on top that specifies "Ultrium 6 - 2500 GB." The IBM Ultrium 5 cartridge is burgundy with a silkscreen label on the top that specifies "Ultrium 5 - 1500 GB."...
Page 172: The Ibm System Storage Lto Data Cartridge
TS3500 Tape Library. The insertion guide 6 is a large, notched area that prevents you from inserting the cartridge incorrectly. You can order tape cartridges with the bar code labels included, or you can order custom labels.
Page 173: Ultrium Cleaning Cartridge
To maintain the operating efficiency of the drive, IBM supplies a cleaning cartridge with the first frame of each media type. Thus if the TS3500 Tape Library contains frames with both LTO Ultrium and 3592 tape drives, IBM supplies one LTO Ultrium cleaning cartridge and one 3592 cleaning cartridge regardless of how many frames of each type are in the library.
Page 174 Enable or disable automatic ejects of expired cleaning cartridges IBM System Storage TS3500 Tape Library with ALMS: Introduction and Planning Guide...
Page 175: Ultrium Diagnostic Cartridge
Table 53 shows the compatability between each generation of diagnostic cartridge and LTO Ultrium tape drive. The characters of the VOLSER are white on a black background. During service calls, your IBM Service Representative will use the cartridge to ensure that the tape drives run correctly and to specification.
Page 176: Ultrium Bar Code Label
Attention: Do not place any type of mark on the white space at either end of the bar code. A mark in this area may prevent the TS3500 Tape Library from reading the label.
Page 177: Guidelines For Using Ultrium Bar Code Labels
LTO bar code label specification, there is no need to slow the scanner speed. For information about slowing the scanner speed, see the section about adjusting the scanner speed in the IBM System Storage TS3500 Tape Library with ALMS Operator Guide.
Page 178: Setting The Write-Protect Switch On An Ultrium Tape Cartridge
If you must manually set the write-protect switch, slide it left or right to the desired position. Figure 37. Setting the write-protect switch on an Ultrium tape cartridge IBM System Storage TS3500 Tape Library with ALMS: Introduction and Planning Guide...
Page 179: Handling Ultrium Tape Cartridges
Incorrect handling or an incorrect environment can damage the IBM LTO Ultrium tape cartridges or their magnetic tape. To avoid damage to your tape cartridges and to ensure the continued high reliability of your IBM LTO Ultrium tape srives, use the following guidelines:...
Page 180: Ensure Proper Packaging Of Ultrium Tape Cartridges
– Double-box the cartridge (place it inside a box, then place that box inside the shipping box) and add padding between the two boxes (see Figure 39 on page 157). IBM System Storage TS3500 Tape Library with ALMS: Introduction and Planning Guide...
Page 181: Provide Proper Acclimation And Environmental Conditions For Ultrium Tape Cartridges
Figure 39. Double-boxing tape cartridges for shipping Provide proper acclimation and environmental conditions for Ultrium tape cartridges v Before you use a cartridge, let it acclimate to the normal operating environment for 1 hour. If you see condensation on the cartridge, wait an additional hour. v Ensure that all surfaces of a cartridge are dry before inserting it.
Page 182: Handle The Ultrium Tape Cartridge Carefully
Do not stack more than six cartridges. v Do not degauss a cartridge that you intend to reuse. Degaussing makes the tape unusable. IBM System Storage TS3500 Tape Library with ALMS: Introduction and Planning Guide...
Page 183: Examples Of Problems With Ultrium Tape Cartridges
Perform the following steps to determine the cause and recover data: 1. Look for cartridge mishandling. 2. Use the IBM Leader Pin Reattachment Kit (part number 08L9129) to correctly position the pin. Then, immediately use data recovery procedures to minimize chances of data loss.
Page 184: Repositioning Or Reattaching A Leader Pin In An Ultrium Cartridge
If the leader pin in your Ultrium tape cartridge becomes dislodged from its pin-retaining spring clips or detaches from the tape, you must use the IBM Leader Pin Reattachment Kit (part number 08L9129) to reposition or reattach it. Do not reattach the pin if you must remove more than 7 meters (23 feet) of leader tape.
Page 185: Placing The Dislodged Leader Pin Into The
Ensure that there are no gaps in the seam of the cartridge 4 . Note: If gaps exist, do not continue with this procedure and do not use the cartridge. Instead, contact your IBM service representative. 4. Close the cartridge door.
Page 186: Reattaching A Leader Pin In An Ultrium Cartridge
Pin supplies (see 3 in Figure 44). Leader pins and C-clips. Attention: v Use only the IBM Leader Pin Reattachment Kit to reattach the leader pin to the tape. Other methods of reattaching the pin will damage the tape, the drive, or both.
Page 187: Attaching The Leader Pin Attach Tool To An
Figure 45. Attaching the leader pin attach tool to an Ultrium tape cartridge. To hold the cartridge door open, hook the tool into the door and pull the tool back. 2. To find the end of the tape inside the cartridge, attach the cartridge manual rewind tool ( 1 in Figure 46 on page 164) to the cartridge's hub 2 by fitting the tool's teeth between the teeth of the hub.
Page 188: Winding The Tape Out Of The Ultrium Tape
When the tape is properly centered, a 0.25-mm (0.01-in.) gap exists on both IBM System Storage TS3500 Tape Library with ALMS: Introduction and Planning Guide...
Page 189: Attaching The Leader Pin To The Tape
sides of the pin. Figure 48. Attaching the leader pin to the tape 12. Close the pivot arm 4 of the leader pin attach tool by swinging it over the leader pin so that the C-clip snaps onto the pin and the tape. 13.
Page 190: Environmental And Shipping Specifications For Ultrium Cartridges
Attention: Depending on how many drives you have installed in the frame of a TS3500 Tape Library, the temperature inside the frame may be as much as 5°C (9°F) above the temperature outside the frame. To ensure continued reliability of your media, be sure to take this temperature difference into account when you set up the environment around your library.
Page 191: Disposing Of Ultrium Tape Cartridges
Disposing of Ultrium tape cartridges This section describes how to dispose of Ultrium tape cartridges according to federal and other regulations. Under the current rules of the U.S. Environmental Protection Agency (EPA), regulation 40CFR261, the LTO Ultrium tape cartridge is classified as non-hazardous waste.
Page 192: Ordering Additional Ultrium Cartridges And Media Supplies
If you would like RFID labels, also specify the feature code provided. IBM System Storage LTO Ultrium 1500 Specify Machine Type 3589 Model 015. GB Data Cartridge Order VOLSER labels separately. IBM System Storage TS3500 Tape Library with ALMS: Introduction and Planning Guide...
Page 193 Table 55. Ordering Ultrium cartridges and media supplies (continued) Feature Codes for RFID Supply Item Method of Ordering Labels IBM System Storage LTO Ultrium 1500 Specify Machine Type 3589 Model 034 FC 3421 GB WORM Data Cartridge and the VOLSER characters that you want.
Page 194: Leader Pin Reattachment Kit
This case can also be used for the Ultrium 2 and Ultrium 1 Tape Cartridges. Leader Pin Reattachment Kit Order as part number 08L9129. Note: N/A = Not applicable IBM System Storage TS3500 Tape Library with ALMS: Introduction and Planning Guide...
Page 195: Ordering Bar Code Labels For Ultrium Cartridges
Bar code labels with volume serial (VOLSER) numbers are required for Ultrium tape cartridges that are read by the TS3500 Tape Library. You can order these labels separately from the IBM data cartridges and cleaning cartridges. Attention: The IBM System Storage TS3500 Tape Library is designed to work with bar code labels that meet the specifications and requirements set forth in the IBM LTO Ultrium Cartridge Label Specification (Revision 2).
Page 196 IBM System Storage TS3500 Tape Library with ALMS: Introduction and Planning Guide...
Page 197: Chapter 5. Using 3592 Tape Drive Media
Chapter 5. Using 3592 tape drive media The section introduces information about the 3592 tape drive media. In addition to automating the storage and movement of IBM LTO Ultrium Tape Cartridges, the TS3500 Tape Library does the same for IBM TotalStorage 3592 Enterprise Tape Cartridges.
Page 198: Types Of Ibm 3592 Totalstorage Enterprise Tape Cartridges
(651.93 GiB) supported (silvery gray) 1 000 GB (931.32 GiB) E06 format Advanced 4 TB Platinum Dark purple 46X7454 WORM, JY (3.64 TiB) supported supported supported (silvery gray) IBM System Storage TS3500 Tape Library with ALMS: Introduction and Planning Guide...
Page 199: Worm Functionality For 3592 Tape Drives And Media
IBM service representatives) through CETool, but is not supported by the Small Computer System Interface (SCSI). For more information, go to the section about updating drive firmware in the IBM System Storage TS3500 Tape Library with ALMS Operator Guide. WORM functionality for 3592 tape drives and media All 3592 tape drives with the appropriate microcode version installed are capable of reading and writing WORM cartridges.
Page 200: Capacity Scaling And Segmentation
Segmentation is only available within a specified range of capacity scaling settings. Capacity scaling is not supported for economy or write-once-read-many (WORM) tapes. For information IBM System Storage TS3500 Tape Library with ALMS: Introduction and Planning Guide...
Page 201 These settings are fully certified and are available as labeled and initialized part-numbered cartridges. For the exact Mode Select commands and settings that are necessary to invoke scaling, see the IBM System Storage 3592 Tape Drive SCSI Reference. Scaling support in drive Capacity scaling in the TS1120 and later tape drives is controlled by the host program performing a Scaling operation.
Page 202: 3592 Data Cartridge
“Overview of 3592 media” on page 173 for these details. TS1120 and newer tape drives that are encryption-enabled perform encryption after compression. Figure 50 on page 179 shows the IBM TotalStorage 3592 Enterprise Tape Cartridge and its components. Cartridge case...
Page 203: Components Of The Ibm Totalstorage 3592
Figure 50. Components of the IBM TotalStorage 3592 Enterprise Tape Cartridge Through its vision system, the TS3500 Tape Library identifies the types of cartridges it contains during an inventory operation. The bar code reader reads the VOLSER (see 3 in Figure 50) of the cartridge bar code label 2 that is in the label area 4 of the cartridge.
Page 204: Cartridge Memory In 3592 Tape Cartridges
Statistical Analysis and Reporting System (SARS). Each cleaning cartridge also contains a CM module, which tracks the number of cleaning uses and the location of the used cleaning media. IBM System Storage TS3500 Tape Library with ALMS: Introduction and Planning Guide...
Page 205: 3592 Cleaning Cartridge
To help prevent errors caused by debris, it is important to clean the tape path of the 3592 tape drives and to manually clean the outside of its data cartridges, when needed. For each TS3500 Tape Library, IBM supplies a specially labeled IBM TotalStorage 3592 Enterprise Cleaning Cartridge with the first 3592 tape drive in the library.
Page 206: Leader Pin In Proper Position In The 3592
(VOLSER) number 2 are CLN. The cartridge door (see 1 in Figure 53 on page 183) is also light gray. Non-moveable light gray block Sample label for cleaning cartridge Figure 52. Characteristics that identify the 3592 cleaning cartridge IBM System Storage TS3500 Tape Library with ALMS: Introduction and Planning Guide...
Page 207: 3592 Diagnostic Cartridge
Model L22 or Model D22 frame for the 3592 diagnostic cartridge. The slot is located at Column 1, Row 1. During a service call, your IBM service representative uses the cartridge to ensure that the tape drives run correctly and to specification.
Page 208 Attention: Do not place any type of mark on the white space at either end of the bar code. A mark in this area may prevent the TS3500 Tape Library from reading the label.
Page 209: Guidelines For Using 3592 Bar Code Labels
*1PJ1H906JA Figure 54. Sample bar code label on the IBM TotalStorage 3592 Enterprise Tape Cartridge. The volume serial number (J1H906JA) and bar code are printed on the label. Guidelines for using 3592 bar code labels Apply the following guidelines whenever you use bar code labels: v Use only IBM-approved bar code labels.
Page 210 Representative. The service procedure for verifying the type of scanner is documented in RPQ 8B3510. v The guidelines for using Silo-style bar code labels with the TS3500 Tape Library must be followed. Proper placement of the bar code label is required for optimum bar code scanner performance.
Page 211: Setting The Write-Protect Switch On A 3592 Cartridge
Setting the write-protect switch on a 3592 Cartridge This section gives instructions for setting the write-protect switch on a 3592 Tape Cartridge. The position of the write-protect switch on the 3592 Tape Cartridge (see Figure 55) determines whether you can write to the tape. v To write data to or erase data from the cartridge, set the switch to 1 .
Page 212: Handling 3592 Tape Cartridges
Incorrect handling or an inhospitable environment can damage the IBM TotalStorage 3592 Enterprise Tape Cartridge or its magnetic tape. To avoid damage to your tape cartridges and to ensure the continued high reliability of your TS3500 Tape Library, use the following guidelines:...
Page 213: Perform A Thorough Inspection Of 3592 Tape Cartridges
v Do not expose recorded or blank cartridges to stray magnetic fields of greater than 50 Oersteds (4000 ampere/meter), such as terminals, motors, video equipment, X-ray equipment, or fields that exist near high-current cables or power supplies. Such exposure can cause the loss of recorded data or make the blank cartridge unusable.
Page 214: Leader Pin In The Incorrect And Correct Positions In A 3592 Tape Cartridge
3 . 3. Press the leader pin gently into the clips until it snaps into place and is firmly seated. 4. Close the cartridge door. IBM System Storage TS3500 Tape Library with ALMS: Introduction and Planning Guide...
Page 215: Placing The Dislodged Leader Pin Into The
Figure 57. Placing the dislodged leader pin into the correct position.. The cartridge door is open, showing the leader pin out of position 5. To rewind the tape, insert the cartridge manual rewind tool (see 1 in Figure 58) into the cartridge's hub 2 and turn it clockwise until the tape becomes taut.
Page 216: Environmental And Shipping Specifications For 3592 Cartridges
Table 58 lists the environmental conditions for operating, storing, and shipping IBM TotalStorage 3592 Enterprise Tape Cartridges. Table 58. Environment for operating, storing, and shipping the IBM TotalStorage 3592 Enterprise Tape Cartridge Environmental Specifications Environmental Factor...
Page 217: Disposing Of 3592 Cartridges
Contact your account representative for information about the materials that are in the cartridge. If a tape cartridge must be disposed of in a secure manner, IBM recommends that you use a qualified service provider to degauss and destroy the media.
Page 218: Ordering 3592 Media Supplies By Using The 3599 Tape Media Method
Ordering 3592 media supplies by using the 3599 tape media method If you order media by using the 3599 tape media method, IBM TotalStorage Enterprise Tape Media 3599 provides the ability to order unlabeled, pre-labeled, initialized, and bulk-packaged data cartridges in a variety of combinations. You can also order cleaning cartridges.
Page 219 Table 59. Descriptions of 3599 tape media features (continued) Feature Code for Labeling, Media ID/ Individual Initialization, and Quantity 3599 Model Feature Format Cartridge Description 2, 5 Code Capacity Regular RFID JC/9035 6200 4 TB 20-pack 3592 Advanced (3.64 TiB) Data cartridges, not labeled and not initialized JJ/9050...
Page 220: Ordering 3592 Media Supplies By Using Part Numbers
Table 60 on page 197 lists the data cartridges and media supplies that you can order for 3592 tape drives by using part numbers. The different methods for ordering are listed at the bottom of the table. IBM System Storage TS3500 Tape Library with ALMS: Introduction and Planning Guide...
Page 221: Ordering Supplies For Repairs
Order by part number through an IBM-authorized distributor (for the closest distributor, visit the web at http://www.ibm.com/storage/media) v If you do not have Internet access, order the cartridges from any authorized IBM business partner or your IBM sales representative.
Page 222: Ordering 3592 Bar Code Labels
This information is provided for the convenience of TS3500 Tape Library users only, and is not an endorsement or recommendation of such providers. IBM is not responsible for the quality of bar code labels procured from sources other than IBM.
Page 223: Chapter 6. Using The Fibre Channel Interface
Chapter 6. Using the Fibre Channel interface This section introduces the use of the Fibre Channel interface with the TS3500 Tape Library. The IBM System Storage TS3500 Tape Library uses a Fibre Channel interface (port) to communicate with servers. Your IBM Service Representative must perform setup and Fibre Channel configuration of the library.
Page 224: Cables And Speeds Of Fibre Channel Drives
This section defines the types of cables that are used by Fibre Channel drives in the TS3500 Tape Library. It also gives the speeds for varying lengths of cables. The Fibre Channel drives in the TS3500 Tape Library use these cables:...
Page 225: Supported Topologies
Supported topologies This section discusses the ways that the Fibre Channel drives in the TS3500 Tape Library connect to other Fibre Channel end points. Fibre Channel devices (such as the TS3500 Tape Library and a server) are known as nodes and have at least one port through which to receive and send data.
Page 226: Two-Node Switched Fabric Topology
Use the two-node switched fabric protocol when attaching the library to an F_port. This protocol is supported when you attach the library through 3592 tape drives or Ultrium 2 and newer tape drives. IBM System Storage TS3500 Tape Library with ALMS: Introduction and Planning Guide...
Page 227: Two-Node Direct Connection Topology
In addition, the TS3500 Tape Library allows you to set the drive port to any of these topologies. To set a port to a topology, see the section about viewing or changing Fibre Channel port speeds and topologies in the IBM System Storage TS3500 Tape Library with ALMS Operator Guide.
Page 228 You can change a Loop ID by using the library's operator panel or Tape Library Specialist Web interface (refer to the section about changing the Loop ID in the IBM System Storage TS3500 Tape Library with ALMS Operator Guide. Using a method called hard addressing, the drive then automatically selects the corresponding AL_PA, which is the identifier that devices use to communicate.
Page 229 Table 65. Valid Loop IDs and their associated AL_PAs for Ultrium tape drives and 3592 tape drives in the IBM System Storage TS3500 Tape Library 7-bit Loop ID 8-bit AL_PA 7-bit Loop ID 8-bit AL_PA 7-bit Loop ID 8-bit AL_PA...
Page 230: Lun Assignments
Table 65. Valid Loop IDs and their associated AL_PAs for Ultrium tape drives and 3592 tape drives in the IBM System Storage TS3500 Tape Library (continued) 7-bit Loop ID 8-bit AL_PA 7-bit Loop ID 8-bit AL_PA 7-bit Loop ID 8-bit AL_PA...
Page 231: Using Persistent Binding To Ensure Scsi Id Assignment
For example, if you have two host bus adapters (HBAs) from the same server connected to a tape drive in the TS3500 Tape Library, the drive will be detected and appear as two logical devices. That is, there will be two special files for one physical device.
Page 232: Connecting The Library To Ibm I, System I, And Iseries
Connecting the library to IBM i, System i, and iSeries This topic provides information that is necessary for connecting the TS3500 Tape Library to a Power System running IBM i or to aSystem i or iSeries server (mainframe host). The IBM i or OS/400 operating system supports a maximum of:...
Page 233: Sharing Drives On A Storage Area Network
These changes are not transparent to System i or iSeries and IBM i or OS/400 servers that are attached to any logical libraries that have changed. Any time that changes are made to the logical library or device configuration, you must reset the associated adapter or perform an initial program load (IPL) of the associated system to reconfigure the changes.
Page 234 IBM System Storage TS3500 Tape Library with ALMS: Introduction and Planning Guide...
Page 235: Chapter 7. Frame Capacity
Chapter 7. Frame capacity This section introduces the quantity of LTO Ultrium tape cartridges and 3592 tape cartridges that the TS3500 Tape Library supports, depending on whether the Capacity On Demand or Capacity Expansion Features are installed, the upper and lower I/O stations are used, and a specified quantity of drives are installed.
Page 236: Capacity Of Model L32 And D32 Frames
10 I/O Slots 1 to 4 5 to 8 9 to 12 (see Note) 1 to 4 5 to 8 9 to 12 Note: N/A = not applicable. IBM System Storage TS3500 Tape Library with ALMS: Introduction and Planning Guide...
Page 237: Capacity Of Model L52, D52, L53, D53, And S54 Frames
Capacity of Model L52, D52, L53, D53, and S54 Frames This section gives the type of eligible Capacity On Demand feature and quantity of drives, I/O slots, and storage slots for Model L52, D52, L53, D53, and S54 frames. Table 68. Quantity of storage slots in Model L52, D52, L53, D53, and S54 frames. The quantity depends on the type of Capacity On Demand Expansion feature installed, whether the upper and lower I/O stations are used, and the quantity of drives in a frame.
Page 238 IBM System Storage TS3500 Tape Library with ALMS: Introduction and Planning Guide...
Page 239: Chapter 8. Tape Encryption Overview
The IBM System Storage TS1120 (3592 Model E05) and TS1130 (3592 Model E06) tape drives are capable of encrypting data as it is written to any size IBM TotalStorage Enterprise Tape Cartridge 3592, including WORM cartridges. The IBM System Storage TS1040 LTO Ultrium 4 and newer Ultrium tape drives are also capable of encrypting data as it is written to any LTO 4 or newer data cartridge.
Page 240: Managing Encryption
(tape and cartridge formats). IBM currently supports the IBM Encryption Key Manager component for the Java platform or the Tivoli Key Lifecycle Manager with the TS3500 Tape Library. The key manager operates on ® z/OS , i5/OS, AIX, Linux, HP-UX, Sun Solaris, and Windows, and is designed to be a shared resource deployed in several locations within an Enterprise.
Page 241: Planning For Application-Managed Encryption
Everything between the application and the tape drives, for example the operating system, z/OS DFSMS, device drivers, and FICON/ESCON controllers. Library Layer The IBM System Storage TS3500 Tape Library, which contains an internal interface to each tape drive within it. Planning for application-managed encryption This topic explains application-managed encryption (AME).
Page 242: Planning For System-Managed Encryption
System z operating environments. Open systems Encryption policies specifying when to use encryption are set up in the IBM tape device driver. System-managed tape encryption and library-managed tape encryption interoperate with one another. In other words, a tape encrypted using system-managed encryption may be decrypted using library-managed encryption, and vice versa, provided they both have access to the same keys and certificates.
Page 243: Planning For Library-Managed Encryption
Refer to the appropriate section of the IBM System Storage TS3500 Tape Library with ALMS Operator Guide for more information.
Page 244: Tape Drive Configuration For Encryption
Note: v In order for encryption to be supported in the TS3500 Tape Library, the rules presented in Table 69 must be followed. Failure to adhere to these rules may result in problems when enabling encryption.
Page 245: Accessibility
Keyboard navigation This product uses standard Microsoft; Windows navigation keys. You can navigate the IBM System Storage TS3500 Tape Library with ALMS Introduction and Planning Guide information from the keyboard by using the shortcut keys for your browser or screen-reader software. See your browser or screen-reader software Help for a list of shortcut keys that it supports.
Page 246 IBM System Storage TS3500 Tape Library with ALMS: Introduction and Planning Guide...
Page 247: Notices
Web sites. The materials at those Web sites are not part of the materials for this IBM product and use of those Web sites is at your own risk.
Page 248: Homologation
Questions on the capabilities of non-IBM products should be addressed to the suppliers of those products. All statements regarding IBM's future direction or intent are subject to change or withdrawal without notice, and represent goals and objectives only. This information is for planning purposes only. The information herein is subject to change before the products described become available.
Page 249: Electronic Emission Notices
IBM, the IBM logo, and ibm.com are trademarks or registered trademarks of International Business Machines Corporation in the United States, other countries, or both. If these and other IBM trademarked terms are marked on their first occurrence in this information with a trademark symbol ((R) or (TM)), these symbols indicate U.S.
Page 250: Industry Canada Compliance Statement
Properly shielded and grounded cables and connectors must be used in order to meet FCC emission limits. IBM is not responsible for any radio or television interference caused by using other than recommended cables and connectors, or by unauthorized changes or modifications to this equipment.
Page 251 Klasse A ein. Um dieses sicherzustellen, sind die Geräte wie in den Handbüchern beschrieben zu installieren und zu betreiben. Des Weiteren dürfen auch nur von der IBM empfohlene Kabel angeschlossen werden. IBM übernimmt keine Verantwortung für die Einhaltung der Schutzanforderungen, wenn das Produkt ohne Zustimmung der IBM verändert bzw.
Page 252: People's Republic Of China Class A Electronic Emission Statement
IBM Taiwan Product Service Contact Information: IBM Taiwan Corporation 3F, No 7, Song Ren Rd., Taipei Taiwan Tel: 0800-016-888 Japan Voluntary Control Council for Interference (VCCI) Class A Statement IBM System Storage TS3500 Tape Library with ALMS: Introduction and Planning Guide...
Page 253: Japan Electronics And Information Technology Industries Association (Jeita) Statement (Less Than Or Equal To 20 A Per Phase)
Japan Electronics and Information Technology Industries Association (JEITA) Statement (less than or equal to 20 A per phase) Korean Communications Commission (KCC) Class A Statement Russia Electromagnetic Interference (EMI) Class A Statement Notices...
Page 254 IBM System Storage TS3500 Tape Library with ALMS: Introduction and Planning Guide...
Page 255: Glossary
If you do not find the term you are looking for, 3593 Tape System see the IBM Glossary of Computing Terms at the The IBM 3953 Tape Frame Model F05 and following web site: http://www.ibm.com/ibm/ the IBM 3953 Library Manager Model terminology.
Page 256 Ampere. and automate the backup, recovery, and media management services for its ampere (A, amp) AS/400 systems. A unit of measure for electric current that IBM System Storage TS3500 Tape Library with ALMS: Introduction and Planning Guide...
Page 257 TS3500 Tape Library, the component that Located on the dual-gripper transport provides the means to find certain mechanism of the TS3500 Tape Library, a positions within the library very precisely laser device specialized for scanning and during the calibration operation.
Page 258 TS3500 Tape Library to library and drive firmware, configure the manage communication to and from a Call Home program for the TS3500 Tape server and the library. IBM System Storage TS3500 Tape Library with ALMS: Introduction and Planning Guide...
Page 259 To make nonfunctional. corresponding equipment in a data door safety switch transmission system. The rate is expressed Located on each frame of the TS3500 Tape in bits, characters, or blocks per second, Library, a mechanism that automatically minute, or hour.
Page 260 Fibre Channel encryption key manager A high-speed, full-duplex, serial A software program that assists communications technology that is IBM-encrypting tape drives in generating, capable of interconnecting Ultrium tape IBM System Storage TS3500 Tape Library with ALMS: Introduction and Planning Guide...
Page 261 The FCB FICON/ESCON-enabled products contains 3 circuit protectors, 10 ac outlets Any of the IBM tape products equipped for powering the tape drives and all other with Fibre Channel (FICON) or Enterprise components in that frame, and a...
Page 262 HD frame. See High Density Capacity on Demand. High Voltage Differential (HVD) HD frame A logic signaling system that enables data See High density frame. IBM System Storage TS3500 Tape Library with ALMS: Introduction and Planning Guide...
Page 263 LTO Ultrium Tape Cartridge. The drive server and the TS3500 Tape Library. HVD houses the mechanism (drive head) that signaling uses a paired plus and minus reads and writes data to the tape. Its ® signal level to reduce the effects of noise native data capacity is 400 GB (372.53...
Page 264: Drives
GB (745.05 GiB) per cartridge; with 2:1 Drive Model E07. compression, its capacity is up to 1.6 TB (1.46 TiB). IBM System Storage TS3500 Tape Library Also known as the 3584 Tape Library, a IBM System Storage TS3500 Tape Library with ALMS: Introduction and Planning Guide...
Page 265 IEEE Institute of Electrical and Electronics Engineers. input/output (I/O) station On the front door of the TS3500 Tape import/export element (IEE) Library, one or two compartments into In SCSI terms, an I/O slot. which you insert and remove cartridges import/export element address (IEEA) into and from the library.
Page 266 KiloVolt enable advanced function. 1 000 volts. lightweight directory access protocol (LDAP) KiloWatt A set of protocols used to access 1 000 watts. information directories. LDAP, an open IBM System Storage TS3500 Tape Library with ALMS: Introduction and Planning Guide...
Page 267 In Fibre Channel technology, the physical or count. The ability of the TS3500 Tape (optical) connection between two nodes of Library to create logical libraries makes it a network, which includes the...
Page 268 Ethernet ports for connection A method by which an operator selects a to the Tape Library Specialist Web menu option from the touchscreen of the interface or a system console. IBM System Storage TS3500 Tape Library with ALMS: Introduction and Planning Guide...
Page 269 Medium Changer card pack (MCC or MCP) and 3592 tape cartridges in the TS3500 In the TS3500 Tape Library, a circuit board Tape Library. A library can consist of that provides a communication path to frames that house all LTO Ultrium tape...
Page 270 Pause key (cgs) electromagnetic system. The Oersted On the touchscreen of the TS3500 Tape is the magnetic field strength in the Library, a touch key that causes the IBM System Storage TS3500 Tape Library with ALMS: Introduction and Planning Guide...
Page 271 See Portable Document Format. power distribution unit (PDU) A unit that provides AC distribution Petabyte within a TS3500 Tape Library frame by 1v000v000v000v000v000 bytes. supplying multiple internal AC outlets ping (1) A command that calls an IP address.
Page 272 A labeled cartridge that is blank or See Call Home. contains no valid data, that is not currently defined, and that is available for use. IBM System Storage TS3500 Tape Library with ALMS: Introduction and Planning Guide...
Page 273 The IBM A value that defines a logical location in pSeries, IBM iSeries, HP, and Sun are the TS3500 Tape Library to the SCSI servers. Synonymous with host. interface. This logical address is service clearance...
Page 274 20 or 40 library strings. Shorter shuttle spans MBps. support distances between library strings ranging from 762 mm (30 in) to 1 524 mm IBM System Storage TS3500 Tape Library with ALMS: Introduction and Planning Guide...
Page 275 The temperature, relative humidity rate, supports data rates of 80 or 160 MBps. and wet bulb temperature of the SMI-S See Storage Management Initiative - environment in which the TS3500 Tape Specification. Library is nonoperational and being stored for future use.
Page 276 To prevent unwanted electrical signal on a tape surface. reflections by applying a device (a transfer rate terminator) that absorbs the energy from See data transfer rate. the transmission line. IBM System Storage TS3500 Tape Library with ALMS: Introduction and Planning Guide...
Page 277 In Fibre Channel technology, the unload connection of two nodes that Pertaining to the TS3500 Tape Library, a communicate directly (without the use of term used to describe the act of the drive a switch) and use the same protocol.
Page 278 5 tape cartridges and 3592 tape cartridges. After being written, the data cannot be altered, but can be read any number of times. write protected A tape cartridge is write protected if some IBM System Storage TS3500 Tape Library with ALMS: Introduction and Planning Guide...
Page 279: Index
Models L52, D52, L53, D53, and clearance specifications 103 average block locate time 81 S54 213 Model S24 average rewind time 81 native Model S54 103 3592 tape cartridges 178 comma-separated value (.csv) format 56 © Copyright IBM Corp. 2008, 2012...
Page 280 20, 24 zoning 202, 207 data compression, in 3592 tape drives 23 key management 215 Fibre Channel interface 30 data gathering, description 56 key stores 216 FICON interface 32 IBM System Storage TS3500 Tape Library with ALMS: Introduction and Planning Guide...
Page 281 40, 41 methods 216 frame control assembly supported 26 key manager description 50 hub, in Fibre Channel network 31 IBM Encryption Key Manager 216 frames Tivoli Key Lifecycle Manager 216 power requirements 120 keyboards front door 13 accessibility features 221, 224...
Page 282 94 ordering tape cartridges and supplies mixed drive types, protection against power cords 124 3592 tape cartridges non-support 40 weight 94 by 3599 tape media method 194 IBM System Storage TS3500 Tape Library with ALMS: Introduction and Planning Guide...
Page 283 ordering tape cartridges and supplies Problem Call Home capability 58 Send us your feedback xiii (continued) problems, resolving serial number, cartridge 3592 tape cartridges (continued) through remote support (Call for 3592 tape cartridges 183 by part number 196 Home) 58, 59 for LTO Ultrium Tape Cartridges 152 LTO Ultrium Tape Cartridges 168 through SNMP messaging 70...
Page 284 LTO Ultrium tape cartridges 167 unassigned, reassigning 49 guidelines for using 185 Economy 173 WORM ordering 183 Economy WORM 173 3592 Tape Cartridge 174, 175 specifications 179, 184 IBM System Storage TS3500 Tape Library with ALMS: Introduction and Planning Guide...
Page 285 3592 Tape Cartridges 192 drive 19, 146 support 63, 67, 68 LTO Ultrium Tape Cartridges 166 LTO Ultrium Tape Drives, TS3500 Command Line Interface 57 for tape library 115 description 13 TS3500 Tape Library What's new maximum quantity...
Page 286 3592 tape cartridges 178, 179 LTO Ultrium Tape Cartridges 147 setting 3592 Tape Cartridges 187 LTO Ultrium Tape Cartridges 154 zone, setting, viewing, or changing preferred accessor 7 zoning 202, 207, 209 IBM System Storage TS3500 Tape Library with ALMS: Introduction and Planning Guide...
Page 287: Tape Library
IBM business partner, or your authorized remarketer. When you send comments to IBM, you grant IBM a nonexclusive right to use or distribute your comments in any way it believes appropriate without incurring any obligation to you. IBM or any other organizations will only use the personal information that you supply to contact you about the issues that you state on this form.
Page 288 Readers’ Comments — We'd Like to Hear from You Cut or Fold Along Line GA32-0593-07 Fold and Tape Please do not staple Fold and Tape _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ NO POSTAGE NECESSARY IF MAILED IN THE...
Page 290 Printed in USA GA32-0593-07...
