B&R Automation Panel 9 D Series User Manual page 95

Model number
Slots
Interface option
4)
Electrical properties
Nominal voltage
Nominal current
Inrush current
Overvoltage category per EN 61131-2
Galvanic isolation
Operating conditions
Pollution degree per EN 61131-2
Degree of protection per EN 60529
Ambient conditions
Elevation
Operation
Mechanical properties
Dimensions
Width
Height
Depth
Weight
1) At max. specified ambient temperature: Typ. 58 ppm (5 seconds) - worst case 220 ppm (19 seconds).
2) Maintenance Controller Extended
3) The SuperSpeed transfer rate (5 Gbit/s) is only possible with USB 3.0.
4) The interface option cannot be replaced.
5) EN 60950 requirements must be observed.
6) Only if all interface covers are installed.
The degree of protection of the complete system depends on the mounting unit used as well as the panel.
7) The maximum ambient temperature is typically derated 1°C per 1000 meters starting at 500 m above sea level.
Automation Panel 9xD - Hygienic design User's manual V 1.80
5PPC2200.AL02-000 5PPC2200.AL04-000
Back: IP20 (front: depends on the panel used)
5PPC2200.AL14-000
1
24 VDC ±25%, SELV
5)
Max. 4 A
Typ. 5 A, max. 50 A for < 500 μs
II
Yes
Pollution degree 2
Max. 3000 m (component-dependent)
190 mm
115 mm
29.7 mm
577 g
Technical data
5PPC2200.AL18-000
6)
7)
95
