4.1.2.1.3 Power calculation with system unit PPC2200
In order to calculate the total power of the Automation Panel, the power rating of the display used must be added to
the power rating of the system unit and the power rating of additional components (CFast card or interface option).
Information:
Unless otherwise stated, the following specified maximum values and additional consumers are not
taken into account.
System unit Order number
PPC2200 E3930 2C 1.30 GHz 5PPC2200.AL02-000
PPC2200 E3930 2C 1.30 GHz 5PPC2200.AL04-000
PPC2200 E3940 4C 1.60 GHz 5PPC2200.AL14-000
PPC2200 E3940 4C 1.60 GHz 5PPC2200.AL18-000
Panels
Type
15" single-touch
15.6" multi-touch with operating ele-
ments
18.5" multi-touch
18.5" multi-touch with operating ele-
ments
19" single-touch
21.5" multi-touch with operating ele-
ments
24.0" multi-touch
CFast cards
Type
SLC technology
MLC technology
Interface options
Type
CAN
POWERLINK CAN X2X
POWERLINK RS485 CAN
POWERLINK
POWERLINK RS232
POWERLINK RS232
POWERLINK RS232 CAN
POWERLINK RS232 CAN X2X
2x RS422/RS485
2x ETH 10/100/1000
4.1.2.1.3.1 Calculation example
15.6" 5AP99D.156B-B62 panel
System unit 5PPC2200.AL14-000
POWERLINK interface option 5ACCIF01.FPLK-000
CFast card 5CFAST.256G-10
