Model number
Flange output
Dimensions
Width
Height
Depth
Weight
1) At 25°C ambient temperature. Reducing the brightness by 50% can increase the half-brightness time by approximately 50%.
2) Under a steam jet, however, the structured coating on the front can become loose. This only affects the appearance of the front; functionality is not impaired.
4.2.1.3.4 Dimensions
Information:
2D and 3D diagrams (DXF and STEP formats) can be downloaded from the B&R website
automation.com).
Automation Panel 9xD - Hygienic design User's manual V 1.80
5.5
(4x)
40
507.2
411.6
320
251.1
80.7
Figure 12: 5AP93D.185B-B62 - Dimensions
5AP93D.185B-B62
Upper and lower
507.2 mm
327.8 mm
141.6 mm
8,800 g
141.6
62.8
31
Technical data
(www.br-
