B&R Automation Panel 9 D Series User Manual page 126

Software
Error messages - RFID stack HIGH byte
Value Name
0x00XX PH_COMP_GENERIC
0x01XX PH_COMP_BAL
0x02XX PH_COMP_HAL
0x03XX PH_COMP_PAL_ISO14443P3A
0x04XX PH_COMP_PAL_ISO14443P3B
0x05XX PH_COMP_PAL_ISO14443P4A
0x06XX PH_COMP_PAL_ISO14443P4
0x07XX PH_COMP_PAL_MIFARE
0x08XX PH_COMP_PAL_FELICA
0x09XX PH_COMP_PAL_EPCUID
0x0AXX PH_COMP_PAL_SLI15693
0x0BXX PH_COMP_PAL_I18000P3M3
0x0CXX PH_COMP_PAL_I18092MPI
0x10XX PH_COMP_AL_MFC
0x11XX PH_COMP_AL_MFUL
0x12XX PH_COMP_AL_MFP
0x13XX PH_COMP_AL_VCA
0x14XX PH_COMP_AL_FELICA
0x15XX PH_COMP_AL_I15693
0x16XX PH_COMP_AL_SLI
0x18XX PH_COMP_AL_I18000P3M3
0x19XX PH_COMP_AL_MFDF
0x1AXX PH_COMP_AL_P40CMDPRIV
0x1BXX PH_COMP_AL_P40CMDPUB
0x30XX PH_COMP_DL_AMP
0x31XX PH_COMP_DL_THSTRM
0x32XX PH_COMP_DL_OSCI
0x33XX PH_COMP_DL_RDFPGA
0x34XX PH_COMP_DL_MSTAMPOSC
0x35XX PH_COMP_DL_STEPPER
0xE0XX PH_COMP_CIDMANAGER
0xE1XX PH_COMP_CRYPTOSYM
0xE2XX PH_COMP_KEYSTORE
0xE3XX PH_COMP_TOOLS
0xE4XX PH_COMP_CRYPTORNG
0xEFXX PH_COMP_LOG
Response Flags
Bit Flag Name
b1 Error Flag
b2 RFU
b3 RFU
b4 Extension flag
b5 RFU
b6 RFU
b7 RFU
b8 RFU
Error Codes
Value Description
01 The request is not supported, i.e., the request code is not recognized
02 The request code is not recognized, for example: a format error occurred.
03 The request option is not supported.
0F Error with no information given or a specific error code is not supported
10 The specified block is not available (does not exist)
11 The specified block is already locked and thus cannot be locked again
12 The specified block is locked and its content cannot be changed
13 The specified block was not successfully programmed
14 The specified block was not successfuly locked
A0 - DF Custom request error codes
All others Reserved for future use
126
Description
Generic Component Code
BAL Component Code
HAL Component Code
ISO14443-3A PAL-Component Code
ISO14443-3B PAL-Component Code
ISO14443-4A PAL-Component Code
ISO14443-4 PAL-Component Code
MIFARE(R) PAL-Component Code
Open FeliCa PAL-Component Code
ICode EPC/UID PAL-Component Code
ICode SLI/ISO15693 PAL-Component Code
ISO18000-3 Mode3 PAL-Component Code
ISO18092 passive initiator mode PAL-Component Code
MIFARE(R) Classic AL-Component Code
MIFARE(R) Ultralight AL-Component Code
MIFARE(R) Plus AL-Component Code
Virtual Card Architecture AL-Component Code
Open FeliCa AL-Component Code
ISO15693 AL-Component Code
ICode SLI AL-Component Code
ISO18000-3 Mode3 AL-Component Code
MIFARE DESFIRE EV1 AL Component Code
P40 command libraryAL-Component Code
P40 command libraryAL-Component Code
Amplifier DL-Component Code
Thermostream DL-Component Code
Oscilloscope DL-Component Code
Reader FPGA Box DL-Component Code
Master Amplifier Oscilloscope DL-Component Code
Stepper DL-Component Code
Cid Manager Component Code
CryptoSym Component Code
KeyStore Component Code
Tools Component Code
CryptoRng Component Code
Log Component Code
Table 47: Error messages - RFID stack HIGH byte
Value Description
0 No error
1 Error detected. Errorcode is in the Error filed response
0 Reserved for future use
0 Reserved for future use
0 High data rate
1 Protocol format is extended. Reserved for future use
0 Reserved for future use
0 Reserved for future use
0 Reserved for future use
0 Reserved for future use
Table 48: Response Flags & Error Codes
Automation Panel 9xD - Hygienic design User's manual V 1.80
