Technical data
4.2.3.2.3 Technical data
Information:
The following specified characteristic data, features and limit values are only valid for these individual
components and may differ from those of the complete system. The data specified for the complete
system applies to the complete system in which this individual component is used, for example.
Model number
General information
Cooling
LEDs
B&R ID code
Power button
Reset button
Buzzer
Certifications
CE
UL
Controller
Bootloader
Processor
Type
Clock frequency
Number of cores
Architecture
Thermal design power (TDP)
L2 cache
Intel 64 architecture
Intel Hyper-Threading Technology
Intel vPro Technology
Intel Virtualization Technology (VT-
x)
Intel Virtualization Technology for
Directed I/O (VT-d)
Enhanced Intel SpeedStep Tech-
nology
Chipset
Trusted Platform Module
Real-time clock
Accuracy
Battery-backed
Power failure logic
Controller
Buffer time
Memory
Type
Memory size
Velocity
Memory interface width
Removable
Graphics
Controller
Max. dynamic graphics frequency
Color depth
DirectX support
OpenGL support
Power management
Interfaces
CFast slot
Quantity
Type
USB
Quantity
Type
Variant
Transfer rate
Current-carrying capacity
Ethernet
Quantity
Variant
Transfer rate
Max. baud rate
94
5PPC2200.AL02-000 5PPC2200.AL04-000
0xF0C6
Intel Atom x5-E3930
1300 MHz
2
6.5 W
2 GB
Single channel
550 MHz
Low speed (1.5 Mbit/s), full speed (12 Mbit/s), high speed (480 Mbit/s) to SuperSpeed (5 Gbit/s)
5PPC2200.AL14-000
Passive via housing
Power, CFast, Link, Run
0xF0C7 0xF0C8
Yes
Yes
No
Yes
cULus E115267
Industrial control equipment
UEFI BIOS
14 nm
2 MB
Yes
No
No
Yes
Yes
Yes
Intel Apollo Lake
TPM 2.0
At 25°C: Typ. 12 ppm (1 second) per day
Yes
MTCX
2)
10 ms
LPDDR4 SDRAM
4 GB
DDR4L-2133
No
Intel HD Graphics
Max. 32-bit
12
4.3
ACPI 5.0
1
SATA III (SATA 6.0 Gbit/s)
2
USB 3.0
Type A
Max. 1 A per connection
2
RJ45, shielded
10/100/1000 Mbit/s
1 Gbit/s
Automation Panel 9xD - Hygienic design User's manual V 1.80
5PPC2200.AL18-000
0xF0C9
Intel Atom x5-E3940
1600 MHz
4
9.5 W
1)
8 GB
Dual channel
600 MHz
3)
