Technical data
Transfer method
SDL operation mode 1
SDL operation mode 2
Single-touch DVI operation
Multi-touch DVI operation
SDL3 operation
SDL4 operation
Front USB
Type
Variant
Transfer rate
Current-carrying capacity
2)
Cable length
USB 2.0
1) In SDL3 operation: Low speed (1.5 Mbit/s), full speed (12 Mbit/s) to high speed (30 Mbit/s)
2) The USB interface is protected by a maintenance-free "USB current-limiting switch" (max. 500 mA).
58
USB type Max. cable length
USB 1.1 40 m
USB 2.0 5 m
USB 2.0 5 m
USB 2.0 5 m
USB 2.0 100 m
USB 2.0 100 m
USB 2.0
Type A, female
Low speed (1.5 Mbit/s), full speed (12
Mbit/s) to high speed (480 Mbit/s)
Max. 500 mA
Max. 5 m (without hub)
-
1)
