7.4.3.6 MIFARE commands - Examples

Befehl:
write,a,0,5,0123456789ABCDEF0123456789ABCDEF
Antwort:
Command write -> Data in sector 1 Block 5 written=0123456789ABCDEF0123456789ABCDEF
Befehl:
read,a,0,5
Antwort:
Command read -> Data in block 5 in HEX=0123456789ABCDEF0123456789ABCDEF
Befehl:
Initzero,a,0,8
Antwort:
Command initzero -> Data in sector 2 Block 8 written=00000000FFFFFFFF0000000000FF00FF
Befehl:
Incr,a,0,8,8,2
Antwort:
Command incr -> Block 008 successful by 0000000002 incremented and written to block 008
Befehl:
read,a,ff ff ff ff ff ff,5
Antwort:
Command read -> Data in Block 5 in HEX=FFFF0000000000000000000000000000
Befehl:
connect,0b a1 78 98
Antwort:
Command connect ->
***************INFO***************
Key_mode = Key_eeprom
Info_text = Info_on
Tag_connected = Manual_mode
Tag_sn = 0BA17898
***********END_OF_INFO************
Befehl:
read_blocks,a,0,0,3
Antwort:
Command read_blocks ->
Data in block 0 in HEX=3B7CF4E05388040046B9949745302809
Data in block 1 in HEX=00000000000000000000000000000000
Data in block 2 in HEX=00000000000000000000000000000000
Data in block 3 in HEX=000000000000FF078069FFFFFFFFFFFF

7.4.4 ISO15693

7.4.4.1 ISO 15693 commands

Command Description
Read Reads a 4-byte block from PICC
Read_Blocks Reads the specified range of blocks from PICC
Write Writes a 4-byte block to PICC
Sys_Info Reads the AFI, DSFID, number of bytes and bytes/block Flags (flag)
Security Displays the write protection status of individual blocks Flags (flag)
Set_AFI Writes the AFI value
120
Parameter 1
Flags (flag)
Flags (flag)
Flags (flag)
Flags (flag)
Table 41: ISO 15693 commands
Automation Panel 9xD - Hygienic design User's manual V 1.80
Parameter 2 Parameter 3 Parameter 4
Source block -- --
Starting block Ending block --
Destination 4-byte data in --
block hex 00h
-- -- --
Starting block Ending block --
1-byte value -- --
Parameter 5
--
--
--
--
--
--
