Technical data

4.1.3.6 Vibration and shock

The following table provides an overview of the maximum vibrations and shock values of the complete system.
Limitations are possible due to individual components.
Automation Panel 9xD
Automation Panel 9xD
1) The specifications refer to a device in its original packaging.
32
Vibration
Operation
9 to 200 Hz: 1 g
(periodic)
Shock
Operation
15 g, 11 ms 2 to 8 Hz: 7.5 mm amplitude
(periodic)
Automation Panel 9xD - Hygienic design User's manual V 1.80
Storage
1)
30 g, 6 ms
Storage
1)
2 to 8 Hz: 7.5 mm amplitude
8 to 200 Hz: 2 g
200 to 500 Hz: 4 g
Transport
1)
30 g, 6 ms
Transport
1)
8 to 200 Hz: 2 g
200 to 500 Hz: 4 g
