B&R Automation Panel 9 D Series User Manual page 75

Model number
Flange output
Dimensions
Width
Height
Depth
Weight
1) At 25°C ambient temperature. Reducing the brightness by 50% can increase the half-brightness time by approximately 50%.
2) Under a steam jet, however, the structured coating on the front can become loose. This only affects the appearance of the front; functionality is not impaired.
4.2.1.4.4 Dimensions
Information:
2D and 3D diagrams (DXF and STEP formats) can be downloaded from the B&R website
automation.com).
Automation Panel 9xD - Hygienic design User's manual V 1.80
5.5
(4x)
40
49
630.2
533.4
320
258.7
79.6
Figure 13: 5AP93D.240C-B62 - Dimensions
5AP93D.240C-B62
Upper and lower
630.2 mm
396.8 mm
141.91 mm
12,300 g
141.91
62
Technical data
31
(www.br-
75
