4.1.4.2 SDL3 receiver (5DLSD3.1001-00)

4.1.4.2.1 Overview
The interfaces available on the device or module are numbered for the purpose of clear differentiation.
The numbering used by the operating system may deviate, however.
No. Interface name
1 USB1
2 USB2
3 SDL3 In
4.1.4.2.2 +24 VDC power supply
Danger!
The device is only permitted to be supplied with a SELV/PELV power supply or with safety extra-low
voltage (SELV) per EN 60950.
The necessary 3-pin connector is not included in delivery; for suitable accessories, see 0TB103.9x.
The device is protected against overload and reverse polarity by a soldered fuse (15 A, fast-acting). If the fuse
is defective (e.g. due to overload), the device must be sent to B&R for repairs. If the polarity is reversed, it is not
necessary to replace the fuse.
Pin
1
2
3
•
Reverse polarity protection
•
3-pin
•
Male
Electrical properties
Nominal voltage
Nominal current
Overvoltage category per EN 61131-2
Galvanic isolation
Uninterruptible power supply
1) EN 60950 requirements must be observed.
Automation Panel 9xD - Hygienic design User's manual V 1.80
(3)
(2)
(1)
Figure 3: Overview of interfaces - SDL3 receiver link module
Chapter
"USB interfaces"
"USB interfaces"
"SDL3 In interfaces"
Description
-
Functional ground
+
(6)
(5)
(4)
No. Interface name
4 SDL3 In LEDs
5 Power 24 VDC
6 Grounding
24 VDC ±25%, SELV
1)
Max. 3 A
II
Yes
No
Technical data
Chapter
"SDL3 In interfaces"
"+24 VDC power supply"
"Grounding"
Figure
1 2 3
