4.1.5.2 System unit PPC2200 (5PPC2200.ALxx-000)

4.1.5.2.1 Overview
1 "IF option slot " on page 56
3 "Ethernet interfaces" on page 52
5 "Power and reset buttons" on page 54
7 "LED status indicators" on page 55
9 "Grounding" on page 51
11 Panel (configuration-dependent)
1) Only available with installed interface option (configuration-dependent, see
4.1.5.2.2 +24 VDC power supply
Danger!
The device is only permitted to be supplied with a SELV/PELV power supply or with safety extra-low
voltage (SELV) per EN 60950.
The necessary 3-pin connector is not included in delivery; for suitable accessories, see
The device is protected against overload and reverse polarity by a soldered fuse (15 A, fast-acting). If the fuse
is defective (e.g. due to overload), the device must be sent to B&R for repairs. If the polarity is reversed, it is not
necessary to replace the fuse.
Pin
1
2
3
•
Reverse polarity protection
•
3-pin
• Male
Electrical properties
Nominal voltage
Nominal current
Overvoltage category per EN 61131-2
Inrush current
Galvanic isolation
Uninterruptible power supply
1) EN 60950 requirements must be observed.
4.1.5.2.2.1 Grounding
Caution!
The functional ground (power supply pin 2 and ground connec-
tion) must be connected to the central grounding point (e.g. con-
trol cabinet or system) via the shortest possible path with the low-
est possible resistance and with the largest possible wire cross
section. This type of grounding is mandatory for proper function-
ality.
Automation Panel 9xD - Hygienic design User's manual V 1.80
Legend
2
4
6
8
10
12
"IF option slot " on page
Description
+
Functional ground
-
Status LEDs of the interface option
Interface option - Terminating resistor
Screw point for cable shield
"CFast slot" on page 48
"USB interfaces" on page 53
"+24 VDC power supply" on page 45
"Battery compartment" on page 56
56).
"0TB103.9x" on page
Figure
24 VDC ±25%, SELV
Typ. 5 A, max. 50 A for < 500 µs
Yes
No
Technical data
1)
1)
130.
1)
II
