4.1.2.1.2 Power calculation with system unit PPC2100
In order to calculate the total power of the Automation Panel, the power rating of the display used must be added to
the power rating of the system unit and the power rating of additional components (CFast card or interface option).
Information:
Unless otherwise stated, the following specified maximum values and additional consumers are not
taken into account.
System unit
PPC2100 E3815 1C 1.46 GHz
PPC2100 E3825 2C 1.33 GHz
PPC2100 E3826 2C 1.46 GHz
PPC2100 E3827 2C 1.75 GHz
PPC2100 E3845 4C 1.91 GHz
PPC2100 E3845 4C 1.91 GHz
Panels
Type
15" single-touch
15.6" multi-touch with operating ele-
ments
18.5" multi-touch
18.5" multi-touch with operating ele-
ments
19" single-touch
21.5" multi-touch with operating ele-
ments
24.0" multi-touch
CFast cards
Type
SLC technology
MLC technology
Type
SLC technology
MLC technology
Interface options
Type
CAN
POWERLINK CAN X2X
POWERLINK RS485 CAN
Automation Panel 9xD - Hygienic design User's manual V 1.80
Order number
5PPC2100.BY01-002
5PPC2100.BY11-002
5PPC2100.BY22-002
5PPC2100.BY34-002
5PPC2100.BY44-002
5PPC2100.BY48-002
Order number +5 V
5AP92D.1505-I00
5AP99D.156B-B62 3.35 W
5AP93D.185B-B62 6.10 W
5AP99D.185B-B62 6.10 W
5AP92D.1906-I00 5 W
5AP99D.215C-B62 7.40 W
5AP93D.240C-B62 6.35 W
Order number +5 V
5CFAST.xxxx-00
5CFAST.032G-10 ≥ G0
5CFAST.064G-10 ≥ E0
5CFAST.128G-10 ≥ E0
5CFAST.032G-10 ≤ F0
5CFAST.064G-10 ≤ D0
5CFAST.128G-10 ≤ D0
5CFAST.256G-10
Order number +5 V
5CFAST.xxxx-00
5CFAST.032G-10
5CFAST.064G-10
5CFAST.128G-10
5CFAST.256G-10
Order number +5 V
5ACCIF01.ICAN-000 0.45 W
5ACCIF01.FPCC-000 0.45 W
5ACCIF01.FPCS-000 0.75 W
Total power consumption
12 W
22 W (with USB consumer)
13 W
23 W (with USB consumer)
15 W
25 W (with USB consumer)
17 W
27 W (with USB consumer)
19 W
29 W (with USB consumer)
20 W
30 W (with USB consumer)
+3.3 V
- 2.1 W
-
-
-
-
-
-
+3.3 V
0.7 W read
- 0.7 W write
0.3 W idle
1.1 W read
- 1 W write
0.25 W idle
1.1 W read
- 1.4 W write
0.25 W idle
0.8 W read
- 1 W write
0.4 W idle
1.2 W read
- 1.9 W write
0.25 W idle
+3.3 V
0.7 W read
- 0.7 W write
0.3 W idle
1.1 W read
- 1 W write
0.25 W idle
1.1 W read
- 1.4 W write
0.25 W idle
1.2 W read
- 1.9 W write
0.25 W idle
+3.3 V
0.05 W
1.55 W
1.00 W
Technical data
+12 V Total
power consumption
8.9 W 11 W
13.85 W
10.50 W
10.80 W 16.90 W
16.90 W
10.80 W
22 W 27 W
25.70 W
18.30 W
24.00 W 30.35 W
+12 V Total
power consumption
0.7 W read
- 0.7 W write
0.3 W idle
1.1 W read
- 1 W write
0.25 W idle
1 W read
- 1.4 W write
0.25 W idle
0.8 W read
- 1 W write
0.4 W idle
1.2 W read
- 1.9 W write
0.25 W idle
+12 V Total
power consumption
0.7 W read
- 0.7 W write
0.3 W idle
1.1 W read
- 1 W write
0.25 W idle
1.1 W read
- 1.4 W write
0.25 W idle
1.2 W read
- 1.9 W write
0.25 W idle
+12 V Total
power consumption
- 0.50 W
- 2.00 W
- 1.75 W
