Technical data
Model number
Features
Emergency stop
Type
Contact element
Optional operating elements
Quantity
Operating conditions
Pollution degree per EN 61131-2
Suitable for hygienic applications
Degree of protection per EN 60529
Degree of protection per UL 50
Mechanical properties
Note
Housing
Material
Front
Frame
Panel overlay
Material
Design
Gasket
Flange output
Dimensions
Width
Height
Depth
Weight
1) At 25°C ambient temperature. Reducing the brightness by 50% can increase the half-brightness time by approximately 50%.
2) Emergency stop according to manufacturer as of October 2019, limitation: nozzle spacing > 250 mm, standard requirement per ISO 20653:2013-02 (IPX9K)
100 - 150 mm
3) Under a steam jet, however, the structured coating on the front can become loose. This only affects the appearance of the front; functionality is not impaired.
80
5AP99D.185B-B62
Schlegel FRVK series
2x normally closed contact, 1x normally open contact
2x prepared cutout
Pollution degree 2
Yes
Back: IP66 (only with flange installed)
Front: IP69K
2)3)
Front: Type 4X indoor use only
The housing is designed for installation on a Rittal CP-
S stainless steel flange (CP6664.500 or CP6664.000)
Stainless steel 1.4301, smoothed
Stainless steel 1.4301, smoothed
Polyester
B&R design
Silicone profile gasket between front and cover
Upper and lower
507.2 mm
369.7 mm
141.6 mm (without emergency stop)
9,550 g
Automation Panel 9xD - Hygienic design User's manual V 1.80
2)
