B&R Automation Panel 9 D Series User Manual page 85

Model number
Operating conditions
Pollution degree per EN 61131-2
Mechanical properties
Dimensions
Width
Height
Depth
Weight
1) The brightness controls can be used to set the brightness of the backlight on the Automation Panel in DVI operation.
2) Yes, but applies only if all components installed in the complete system have this certification and the complete system bears the corresponding mark.
3) The following Automation Panel link module interfaces are not approved for use in DNV GL ambient conditions: COM, USB.
4) Yes, but applies only if all components installed in the complete system have this certification and are listed on the associated DNV GL certificate for the
product family.
5) Max. USB 1.1 is possible in "SDL operation without USB cable".
6) For the 2 USB type A female connectors.
7) EN 60950 requirements must be observed; see section "+24 VDC power supply" of the user's manual.
Automation Panel 9xD - Hygienic design User's manual V 1.80
5DLSDL.1001-00
Pollution degree 2
190 mm
110 mm
23.6 mm
538 g
Technical data
85
