Technical data
Model number
Ethernet
Quantity
Variant
Transfer rate
Max. baud rate
Slots
Interface option
7)
Electrical properties
Nominal voltage
Nominal current
Inrush current
Overvoltage category per EN 61131-2
Galvanic isolation
Operating conditions
Pollution degree per EN 61131-2
Degree of protection per EN 60529
Ambient conditions
Elevation
Operation
Mechanical properties
Dimensions
Width
Height
Depth
Weight
1) Yes, but applies only if all components installed in the complete system have this certification and the complete system bears the corresponding mark.
2) Yes, but applies only if all components installed in the complete system have this certification and are listed on the associated DNV GL certificate for the
product family.
3) At max. specified ambient temperature: Typ. 58 ppm (5 seconds) - worst case 220 ppm (19 seconds).
4) To achieve the specified values for the self-discharge time, the product must be supplied with power for min. 8 hours.
5) Maintenance Controller Extended
6) The SuperSpeed transfer rate (5 Gbit/s) is only possible with USB 3.0.
7) The interface option cannot be replaced.
8) EN 60950 requirements must be observed; see section "+24 VDC power supply" of the user's manual.
9) Only if all interface covers are installed.
10) The maximum ambient temperature is typically derated 1°C per 1000 meters starting at 500 m above sea level.
92
5PPC2100. 5PPC2100.
BY01-000 BY11-000
Back: IP20 (front: depends on the panel used)
5PPC2100. 5PPC2100.
BY22-000 BY34-000
2
RJ45, shielded
10/100/1000 Mbit/s
1 Gbit/s
1
24 VDC ±25%
8)
3.5 A
Typ. 6 A, max. 10 A for < 300 μs
II
Yes
Pollution degree 2
Max. 3000 m (component-dependent)
190 mm
115 mm
29.7 mm
577 g
Automation Panel 9xD - Hygienic design User's manual V 1.80
5PPC2100. 5PPC2100.
BY44-000 BY48-000
9)
10)
