Technical data

4.1.2 Electrical properties

4.1.2.1 Power calculation

4.1.2.1.1 Power calculation with link module
In order to calculate the total power of the Automation Panel, the power rating of the display being used must be
added to the power rating of the link module being used.
Information:
Unless otherwise stated, the following specified maximum values and additional consumers are not
taken into account.
Type Order number
SDL/DVI receiver 5DLSDL.1001-00
SDL3 receiver 5DLSD3.1001-00
SDL4 receiver 5DLSD4.1001-00
Panels
Type
15" single-touch
15.6" multi-touch with operating ele-
ments
18.5" multi-touch
18.5" multi-touch with operating ele-
ments
19" single-touch
21.5" multi-touch with operating ele-
ments
24.0" multi-touch
Example:
15.6" 5AP99D.156B-B62 panel
5DLSDL.1001-00 SDL/DVI receiver
22
Order number +5 V
5AP92D.1505-I00
5AP99D.156B-B62 3.35 W
5AP93D.185B-B62 6.10 W
5AP99D.185B-B62 6.10 W
5AP92D.1906-I00 5 W
5AP99D.215C-B62 7.40 W
5AP93D.240C-B62 6.35 W
3.35 W + 10.50 W =
8.6 W (with USB consumers)
Total max.:
Total power consumption of link module
Max. 3.6 W
Max. 8.6 W (with USB consumer)
Max. 8.1 W
Max. 13.1 W (with USB consumer)
Max. 8.1 W
Max. 13.1 W (with USB consumer)
+3.3 V
- 2.1 W
-
-
-
-
-
-
13.85 W
8.60 W
22.45 W
Automation Panel 9xD - Hygienic design User's manual V 1.80
+12 V Total
power consumption
8.9 W 11 W
13.85 W
10.50 W
10.80 W 16.90 W
16.90 W
10.80 W
22 W 27 W
25.70 W
18.30 W
24.00 W 30.35 W
