A.C Touch screen

A.C.1 Touch screen (single-touch)

A.C.1.1 Technical data

Information:
The following specified characteristic data, features and limit values are only valid for these individual
components and may differ from those of the complete system. The data specified for the complete
system applies to the complete system in which this individual component is used, for example.
Model number
General information
Technology
Release pressure
Light transmission
Operating conditions
Activation
Ambient conditions
Temperature
Operation
Storage
Transport
Relative humidity
Operation
Storage
Transport

A.C.1.2 Temperature/Humidity diagram

(1) Operation
(2) Storage and transport

A.C.2 3M touch screen (multi-touch generation 3)

A.C.2.1 Technical data

Information:
The following specified characteristic data, features and limit values are only valid for these individual
components and may differ from those of the complete system. The data specified for the complete
system applies to the complete system in which this individual component is used, for example.
Model number
General information
Technology
Light transmission
Anti-glare coating
Automation Panel 9xD - Hygienic design User's manual V 1.80
Table 71: Touchscreen ST cHMI - Technical data
RH [%]
Table 72: Touchscreen 3M - Technical data
Touchscreen ST cHMI
Analog resistive
<1 N
Up to 78%
Finger, thin glove, pen, credit card
-10 to 50°C
-20 to 70°C
-20 to 70°C
90% at max. 35°C; see diagram.
90% at max. 50°C for max. 240 h; see diagram.
90% at max. 50°C for max. 240 h; see diagram.
(1) (2)
Diagram legend
T [°C] Temperature in °C
RH [%] Relative humidity (RH) in percent and non-condensing
Touchscreen 3M
Projected capacitive touch (PCT)
>90%
Optical/Gloss = 80
Appendix A
T [°C]
151
