Technical data
4.1.4.1.4.1 Cable lengths and resolutions for SDL transfer
The following table shows the relationship between segment length and maximum resolution depending on the
SDL cable:
SDL cable
VGA
Segment length [m]
640 x 480
0.8
5CASDL.0008-00 5CASDL.0008-00 5CASDL.0008-00 5CASDL.0008-00 5CASDL.0008-00 5CASDL.0008-00 5CASDL.0008-00
5CASDL.0018-00
1.8
5CASDL.0018-01
5CASDL.0018-03
5CASDL.0050-00
5 5CASDL.0050-01
5CASDL.0050-03
6 5CASDL.0060-00 5CASDL.0060-00 5CASDL.0060-00 5CASDL.0060-00 5CASDL.0060-00 5CASDL.0060-00 5CASDL.0060-00
5CASDL.0100-00
10 5CASDL.0100-01
5CASDL.0100-03
5CASDL.0150-00
15 5CASDL.0150-01
5CASDL.0150-03
5CASDL.0200-00
20
5CASDL.0200-03
5CASDL.0250-00
25
5CASDL.0250-03
5CASDL.0300-00
30
5CASDL.0300-03
40 5CASDL.0400-13 5CASDL.0400-13 5CASDL.0400-13 5CASDL.0400-13 5CASDL.0400-13
4.1.4.1.4.2 Cable lengths and resolutions for DVI transfer
The following table shows the relationship between segment length and maximum resolution depending on the
DVI cable:
DVI cable
VGA
Segment length [m]
640 x 480
1.8
5CADVI.0018-00 5CADVI.0018-00 5CADVI.0018-00 5CADVI.0018-00 5CADVI.0018-00 5CADVI.0018-00 5CADVI.0018-00
5 5CADVI.0050-00 5CADVI.0050-00 5CADVI.0050-00 5CADVI.0050-00 5CADVI.0050-00 5CADVI.0050-00 5CADVI.0050-00
The maximum cable length for DVI transfer is limited to 5 m due to the USB specification.
36
SVGA XGA
800 x 600 1024 x 768
5CASDL.0018-00 5CASDL.0018-00
5CASDL.0018-01 5CASDL.0018-01
5CASDL.0018-03 5CASDL.0018-03
5CASDL.0050-00 5CASDL.0050-00
5CASDL.0050-01 5CASDL.0050-01
5CASDL.0050-03 5CASDL.0050-03
5CASDL.0100-00 5CASDL.0100-00
5CASDL.0100-01 5CASDL.0100-01
5CASDL.0100-03 5CASDL.0100-03
5CASDL.0150-00 5CASDL.0150-00
5CASDL.0150-01 5CASDL.0150-01
5CASDL.0150-03 5CASDL.0150-03
5CASDL.0200-00 5CASDL.0200-00
5CASDL.0200-03 5CASDL.0200-03
5CASDL.0250-00 5CASDL.0250-00
5CASDL.0250-03 5CASDL.0250-03
5CASDL.0300-00 -
5CASDL.0300-03 5CASDL.0300-13
SVGA XGA
800 x 600 1024 x 768
Resolution
HD SXGA
1366 x 768 1280 x 1024
5CASDL.0018-00 5CASDL.0018-00
5CASDL.0018-01 5CASDL.0018-01
5CASDL.0018-03 5CASDL.0018-03
5CASDL.0050-00 5CASDL.0050-00
5CASDL.0050-01 5CASDL.0050-01
5CASDL.0050-03 5CASDL.0050-03
5CASDL.0100-00 5CASDL.0100-00
5CASDL.0100-01 5CASDL.0100-01
5CASDL.0100-03 5CASDL.0100-03
5CASDL.0150-00 5CASDL.0150-00
5CASDL.0150-01 5CASDL.0150-01
5CASDL.0150-03 5CASDL.0150-03
5CASDL.0200-00 5CASDL.0200-00
5CASDL.0200-03 5CASDL.0200-03
5CASDL.0250-00 -
5CASDL.0250-03 -
- -
5CASDL.0300-13 5CASDL.0300-13
Resolution
HD SXGA
1366 x 768 1280 x 1024
Automation Panel 9xD - Hygienic design User's manual V 1.80
UXGA FHD
1600 x 1200 1920 x 1080
5CASDL.0018-00 5CASDL.0018-00
5CASDL.0018-01 5CASDL.0018-01
5CASDL.0018-03 5CASDL.0018-03
5CASDL.0050-00 5CASDL.0050-00
5CASDL.0050-01 5CASDL.0050-01
5CASDL.0050-03 5CASDL.0050-03
5CASDL.0100-00 5CASDL.0100-00
5CASDL.0100-01 5CASDL.0100-01
5CASDL.0100-03 5CASDL.0100-03
- -
- -
- 5CASDL.0150-03
- -
- 5CASDL.0200-03
- -
- -
- -
- 5CASDL.0300-13
- 5CASDL.0400-13
UXGA FHD
1600 x 1200 1920 x 1080
