Technical data

4.1.3 Environmental properties

4.1.3.1 Temperature specifications

Because it is possible to combine different link modules, panel PCs and panels, the following table provides a
component-dependent overview of the maximum ambient temperatures resulting from these combinations.
Information:
The maximum specified ambient temperatures for operation were determined under worst-case con-
ditions. Experience has shown that higher ambient temperatures can be achieved with typical appli-
cations in Microsoft Windows, for example. The relevant test and assessment must be carried out in-
dividually by the user on site (reading out the temperatures in BIOS or using the B&R Control Center,
for example).
Information about worst-case conditions
• Thermal Analysis Tool (TAT) from Intel for simulating processor utilization (100% CPU, 100% memory,
100% graphic)
• BurnInTest 7.1 from PassMark Software for simulating 100% interface utilization using loopback adapters
(100% network)
• 2x 1 A USB load
• Maximum expansion and power consumption of the system
• 100% display brightness
