– USING THE MACHINE –
REMARK
• The valve for the remote draining function is controlled by the remote control located right
next to the lid on the spray mixture tank.
• The valve is kept under pressure by a spring but can be held open by pulling the cord and
then jamming it into the V-shaped slot located on the puller mount.
• To better drain the spray mixture tank, switch off tank bottom agitation.
5.10.1.7 Filter equipment
IMPORTANT
• Use all filters provided. Regularly clean the filters (refer to the chapter
MACHINE MAINTENANCE ). Only perfect filtration of the spray mixture will ensure correct
operation of the sprayer. Perfect spray mixture filtration considerably influences the success of the
phytosanitary measures.
Respect the approved combinations of filters or the mesh sizes.
• Remember that the use of filter cartridges of 80 or 100 meshes/inch can cause on certain
phytosanitary products, filtration of the active materials. Check for each product with the
manufacturer of the phytosanitary products.
• The suction filter (a 365 or 594 micron filter, depending on the
application) (1), filters the spray mixture and the water for filling
sucked up by the pump.
• The (500 micron) filter of the pressure gauge (2) protects the
pressure gauge.
• The (500 micron) filling filter (3), prevents dirtying of the spray
mixture and acts as a filter when using the filler pipe.
Fig.42
MAy-2015
Fig.41
1
Fig.43
3
2
