– COMMISSIONING THE MACHINE –
6. Stop the tractor's engine, disengage the PTO and remove the ignition key.
7. Connect the drive shaft and all of the harnesses and feed pipes.
8. Adjust the stabilisers of the lower arms so that the sprayer is centred and to eliminate the lateral play.
9. Attach the safety cable
10. Remove the stand and store it in the location provided. Read the "Stand" paragraph in chapter
USING THE MACHINE of this manual.
WARNING
The drive shaft may become damaged due to contact with the safety cable!
Attach the safety cable to the tractor so that it does not interfere with the drive shaft.
4.2.7.3 Uncoupling
1. Fit the stand. Read the "Stand" paragraph in chapter USING THE MACHINE of this manual.
2. Detach the safety cable from the tractor.
3. Uncouple the drive shaft and place it on its support.
4. Disconnect the electrical lines.
5. Remove the safety pins from the coupling shafts.
6. Uncouple the ball joints from the tractor arms.
7. Disconnect the hydraulic hoses and store them on the support provided.

4.2.8 - INSTALLATION OF THE DRIVE SHAFT TRANSMISSION

WARNING
Risk of accidents due to
• Projection of damaged and/or destroyed parts if the drive shaft is compressed or elongated due to
unsuitable length.
• Snagging or dragging in in case of incorrect assembly or unauthorised modification of the drive shaft.
Respect the instructions when adapting the machine.
Check the length of the drive shaft in all operating positions.
WARNING
Risk of crushing due to
• Accidental movement of the tractor and the machine!
• Lowering of the raised machine!
Before entering the danger zone between the tractor and the machine to adapt the drive shaft, take all
necessary measures to prevent the tractor or the machine from starting or moving accidentally and the
accidental lowering of the raised machine..
C
to a solid part of the rear of the tractor (3).
