– USING THE MACHINE –
WARNING
Risk of accidents in case of accidental contact with the spray mixture!
Risks of pollution in case of overflow via the filling hole!
After filling ensure the filling hole cover is correctly closed and locked.
5.10.1.5 Agitation of the spray mixture tank
The machine is equipped with hydraulic agitators which operate as soon as the
spraying pump is started.
Starting agitation is triggered by the valves (D and E) located on the front face
of the machine.
Read the paragraph on "Agitating the mixture tank" in this chapter.
5.10.1.6 Draining the spray mixture tank
WARNING
Risk of accidents in case of accidental contact with the spray mixture!
Always wear gloves.
WARNING
Risks of pollution to ground during draining!
Ensure that the spray mixture is not sprayed onto the ground, even when diluted.
Use a retention tank .
1. Remove the (yellow) safety plug.
2. Pull on the cord used to
remotely drain the tank.
Fig.39
MAy-2015
D
E
Fig.38
1
2
Fig.40
