– DECRIPTION OF THE MACHINE –
4.4.3.2 Maximum height of the machine at work
DANGER
Risk of electrocution through electrical contact with the boom!
Be extremely careful when performing boom manoeuvres.
Equipment
VITIFIX boom
VITIMOBIL boom
VITIMOBIL boom
PRECIJET
VITISIT II boom
VITIVARIO boom
VITIVARIO boom
PRECIJET
VITIVARIO GV boom
STANDARD PRECIJET
VITIVARIO GV boom
LONG PRECIJET
(a) to be defined

4.4.4 - TANK CHARACTERISTICS

Filling capacity (with water)
Machines
800 narrow
1000 narrow
1000 wide
1200 litres
The overflow capacity is at least +5% of the rated capacity
(+ 5% in compliance with standard ISO/FDIS 4254-6)
max H
in meters
(highest wheels)
(a)
(a)
(a)
max H
(a)
(a)
(a)
2.60
(a)
Main tank
800 litres
1000 litres
1000 litres
1200 litres
Rinsing tank
80 litres
80 litres
120 litres
120 litres
MAy-2015
Fig.8
Hand wash
15 litres
15 litres
15 litres
15 litres
