Workstations - Tecnoma VECTIS 800e Adjustments, Use And Maintenance

– USING THE MACHINE –

5.5 - WORKSTATIONS

C
Fig.3
Fig.4
Fig.9
1
2
Eductor with open cover
(1)
Function selection valve
(G) Control valve for the hopper rinsing gun
(R) Valve controlling tank returns from decompressions
(B) Control valve for incorporation or LAV'TON washers
(D) Control valve for the front agitation
(F) Eductor accessory valve
F
D
E
A
B
Fig.7
H
G
LAV' BOX in operating position
(2)
Suction selector valve
(H) Control valve for the LAV'BOX
(A) Suction valve
(C) Accessory valve / Regulation activation
(E) Control valve for the rear agitation
MAy-2015
A
B
F
Fig.6
Fig.8
R
Fig.5
D
E
63
