2 SPECIFICATIONS
2.1 General features
DUALACE2 NEW GENERATION inverter is a controller designed to control a
pair of AC induction, PMSM, SRM and SRPM motors, in the range from 4 kW to
12 kW continuous power, used in a variety of battery-powered material handling
trucks.
Typical applications include, but are not limited to: counterbalanced trucks with
load up to 3 tons, HLOP (VNA), reach truck, tow tractors, airport ground support
vehicles, aerial-access equipment (telescopic boom and scissor lift), e-mobility
vehicles.
The main inverter features are:
2.2 Technical specifications
Motor type: ................................................................. ACIM, PMSM, SRM, SRPM
Control mode: .................................................................... speed or torque control
Operating frequency: .................................................................................... 8 kHz
Ambient operating temperature range: ........................................... -40 °C ÷ 40 °C
Ambient storage temperature range: .............................................. -40 °C ÷ 85 °C
Maximum inverter temperature (at full power): .............................................. 85 °C
Connector: .......................................................................... 23 or 35-pins Ampseal
Package environmental rating: ....................................................................... IP65
AFNZPxxx– DUALACE2 NEW GENERATION – User Manual
16-bits real time signal controller for motor control and main functions.
16-bits real time signal controller for safety functions.
Field-oriented motor control.
Compatible with several types of speed/position sensors:
o 2 x Incremental encoder
o 2 x sin/cos sensors
o 2 x set of hall sensors
Low-side driver for a line-contactor coil.
Low-side drivers for electromechanical-brake coils
Driver for a proportional valve (PWM current controlled).
High-side driver for electromechanical-brake
Thermal cutback, warnings and automatic shutdown for protection of
motor and controller.
ESD-protected.
Software downloadable via serial link (internal connector) or CAN bus
(external connector).
Diagnostic provided via CAN bus using Zapi PC CAN Console.
Rugged sealed housing and connectors meet IP65 environmental sealing
standards for use in harsh environments.
Page 11/169
