Pin
Type
A19
Output
NEB_L
A20
Output
A21
Output
CANH
Input
PTH_R
A22
A23
Input
PTH_L
4.2.2 Premium version
DUALACE2 NEW GENERATION Premium is equipped with a 35-poles Ampseal
connector like that of the figure. Each of the 35 pins is referred to as "A#", where
"A" denotes the connector name and "#" the pin number, from 1 to 35.
For each I/O pin, the default Zapi function is indicated. The function of each pin
can be changed in the customized software.
Some I/O pins can have special functionality depending on controller
configuration.
4.2.3 Dual AC traction configuration
Pin
Type
A1
Input
Page 32/169
DUALACE2 NEW GENERATION Standard
Name
Driving output for the left-hand side electromechanical brake
(driving to -B); PWM controlled; 3 A maximum continuous
current.
CANL
Low-level CAN bus line.
High-level CAN bus line.
Analog input for the thermal sensor of the right-hand side traction
motor.
Internal pull-up is a 2 mA current source.
Analog input for the thermal sensor of the left-hand side traction
motor.
Internal pull-up is a 2 mA current source.
35-poles Ampseal connector of DUALACE2 NEW GENERATION Premium.
DUALACE2 NEW GENERATION (dual traction)
Name
Description
Digital input, active when connected to -B.
SPARE
The default function is not defined.
Description
AFNZPxxx – DUALACE2 NEW GENERATION – User Manual
