Protection
PTH input is protected against short circuits to +B and ESD protected by
suppressor device. A low-pass filter attenuates the noise from the motor.
Connector position
4.4.10 Sensor supply
Supplies for external motor-speed sensors are available between pin PENC_R
A10
(A8) and pin NENC_R
NENC_R
Output voltage is configurable via hardware by internal jumper to +12V or +5V;
the maximum output current is 200 mA.
Actual values for "+12V" and "+5V" are respectively 12.1 V ± 0.5 V and
5 V ± 0.3 V.
Protection
Sensor supply has a current limiter at 200 mA and it is protected against
accidental connection to +B with a diode.
Connector position
4.4.11 CAN bus
CAN bus interface is available for communication with the controller, featuring:
Page 48/169
Standard
A22, A23
A15
(A9).
Standard
A8, A15
Standard
A2, A9
Physical Interface according to ISO 11898-2.
Data rate can be 125, 250 or 500 kbit/s.
CAN driver is +5 V supplied and provides a rail to rail signal on the
differential output (CANH - CANL).
An internal 120 Ω termination resistor can be built-in.
A21
(A15) and between pin PENC_L
AFNZPxxx – DUALACE2 NEW GENERATION – User Manual
Premium
A32, A33
A4
(A2) and pin
Premium
A10, A21
Premium
A4, A15
