Parameter
CTRAP HW
(A)
CTRAP THRESOLD
(A)
TRUCK SPEED
(A)
ODOMETER KM
(A)
CPU TIME F US
(A)
CPU TIME M US
(A)
NODE ID
(CO)
TARGET SPEED
(CO)
BRAKING REQUEST
(CO)
CONTROL WORD
(CO)
CONTROL WORD 2
(CO)
STATUS WORD
(CO)
WARNING SYSTEM
(CO)
TARGET EVP1
(CO)
TORQUE REQ.
(CO)
TORQUE BRK REQ.
(CO)
Page 100/169
TESTER (Master µC)
Unit of measure
(resolution)
Number (1)
Volt (0.01 V)
km/h (0.1 km/h)
km (1 km)
-
-
1- 126
10∙Hz
0-255
0-65535
0-65535
0-65535
0-65535
% (1%)
% (255 steps)
% (255 steps)
AFNZPxxx – DUALACE2 NEW GENERATION – User Manual
Description
Counter showing the number of occurrences of hardware-
overcurrent detection.
Threshold voltage of the overcurrent detection circuit.
Speed of the truck (it requires custom software embedding
gear ratio and wheels radius).
Odometer: overall distance traveled by the truck.
Reserved for Zapi technicians use.
Reserved for Zapi technicians use.
CAN node ID used by controller
Speed setpoint transmitted over CAN bus. It is expressed
in tenths of Hz.
Braking setpoint transmitted over CAN bus.
Control word transmitted over CAN bus.
Status word 2 travelling over CAN bus.
Status word travelling over CAN bus.
Warning code (in case of warning).
Setpoint of the proportional electrovalve EVP1 transmitted
over CAN bus.
Torque setpoint of the motor transmitted over CAN bus,
expressed as percentage of the maximum torque.
Breaking torque setpoint of the motor transmitted over
CAN bus, expressed as percentage of the maximum
torque.
