Parameter
INVERS. BRAKING
(A)
DECEL. BRAKING
(A)
PEDAL BRAKING
(A)
SPEED LIMIT BRK.
(A)
STEER BRAKING
(A)
MAX SPEED FORW
(A)
MAX SPEED BACK
(A)
CUTBACK SPEED 1
(A)
CTB. STEER ALARM
(A)
CURVE SPEED 1
(A)
CURVE SPEED 2
(A)
Page 72/169
PARAMETER CHANGE
Allowable range
0.1 s ÷ 25.5 s
(steps of 0.1 s)
0.1 s ÷ 25.5 s
(steps of 0.1 s)
0.1 s ÷ 25.5 s
(steps of 0.1 s)
0.1 s ÷ 25.5 s
(steps of 0.1 s)
0.1 s ÷ 25.5 s
(steps of 0.1 s)
0% ÷ 100%
(steps of 1%)
0% ÷ 100%
(steps of 1%)
10% ÷ 100%
(steps of 1%)
0% ÷ 100%
(steps of 1%)
0% ÷ 100%
(steps of 1%)
1% ÷ 100%
(steps of 1%)
AFNZPxxx – DUALACE2 NEW GENERATION – User Manual
Description
This parameter defines the deceleration ramp performed
when the direction switch is toggled during drive, i.e. the
time needed to decelerate the motor from 100 Hz down to
0 Hz.
A special software feature manages the deceleration ramp
depending on the starting speed (see paragraph 0).
This parameter defines the deceleration ramp performed
when the accelerator is released but not completely, i.e.
the time needed to decelerate the motor from 100 Hz down
to 0 Hz.
A special software feature manages the deceleration ramp
depending on the starting speed (see paragraph 0).
This parameter defines the deceleration ramp performed
when the braking pedal is pressed, i.e. the time needed to
decelerate the motor from 100 Hz down to 0 Hz.
A special software feature manages the deceleration ramp
depending on the starting speed (see paragraph 0).
This parameter defines the deceleration ramp performed
upon a speed-reduction request, i.e. the time needed to
decelerate the motor from 100 Hz down to 0 Hz.
A special software feature manages the deceleration ramp
depending on the starting speed (see paragraph 0).
This parameter defines the deceleration ramp related to
the steering angle, i.e. the time needed to decelerate the
motor from 100 Hz down to 0 Hz.
A special software feature manages the deceleration ramp
depending on the starting speed (see paragraph 0).
This parameter defines the maximum speed in forward
direction as a percentage of TOP MAX SPEED.
This parameter defines the maximum speed in backward
direction as a percentage of TOP MAX SPEED.
This parameter defines the maximum speed performed
when cutback input 1 is active. It represents a percentage
of TOP MAX SPEED.
This parameter defines the maximum traction speed when
an alarm from the EPS is read by the microcontroller, if the
alarm is not safety-related. The parameter represents a
percentage of TOP MAX SPEED.
This parameter defines the maximum traction speed when
the steering angle is equal to the STEER ANGLE 1 angle.
The parameter represents a percentage of TOP MAX
SPEED.
This parameter defines the maximum traction speed when
the steering angle is equal to the STEER ANGLE 2 angle.
The parameter represents a percentage of TOP MAX
SPEED.
