8.2.6 Special Adjustment
Note: SPECIAL ADJUST. must only be accessed by skilled people. To change
settings in this group of settings, a special procedure is needed. Ask for this
procedure directly to a Zapi technician. In SPECIAL ADJUST. there are
factory-adjusted parameters that should be changed by expert technicians only.
Parameter
M ADJUSTMENT #01
(Read Only)
(A)
M ADJUSTMENT #02
(Read Only)
(A)
S ADJUSTMENT #01
(Read Only)
(A)
S ADJUSTMENT #02
(Read Only)
(A)
DIS.CUR.FALLBACK
(A)
SET CURRENT
(Read Only)
(A)
M SET TEMPERAT.
(A)
S SET TEMPERAT.
(A)
HW BATTERY RANGE
(Read Only)
(A)
Page 90/169
SPECIAL ADJUSTMENTS
Allowable range
OFF ÷ ON
0°C ÷ 255°C
(steps of 1°C)
0°C ÷ 255°C
(steps of 1°C)
0 ÷ 3
(steps of 1)
AFNZPxxx – DUALACE2 NEW GENERATION – User Manual
Description
First gain of the first traction-motor current-sensing
amplifier.
NOTE: only Zapi technicians can change this value through
a special procedure.
Second gain of the first traction-motor current-sensing
amplifier.
NOTE: only Zapi technicians can change this value through
a special procedure.
First gain of the second traction-motor current-sensing
amplifier.
NOTE: only Zapi technicians can change this value through
a special procedure.
Second gain of the second traction-motor current-sensing
amplifier.
NOTE: only Zapi technicians can change this value through
a special procedure.
This parameter disables or enables current reduction
(applied after one minute of traction).
ON = Current reduction is disabled.
OFF = Current reduction is enabled.
(Factory adjusted). This is maximum current that the
inverter can provide to the motor.
This parameter calibrates the master controller-temperature
reading.
This parameter calibrates the slave controller-temperature
reading.
This parameter defines the battery voltage range.
NOTE: only Zapi technicians can change this value.
