Pin
Type
A2
Input
A3
Input
A4
Output
A5
Input
A6
Input
A7
Input
A8
Input
A9
Input
A10
Output
PENC_R
A11
Input
A12
Input
A13
Input
A14
Input
A15
Output
A16
Input
CPOT BR
AFNZPxxx– DUALACE2 NEW GENERATION – User Manual
DUALACE2 NEW GENERATION (dual traction)
Name
Description
Digital input, inactive when connected to -B, active when the
switch is open.
SR/HB
The default function is as speed-reduction or handbrake
request (see parameter HB ON / SR OFF, paragraph 8.2.3).
KEY
Input of the key switch signal.
Positive supply for the left-hand side encoder and for
PENC_L
potentiometers (+5 V or +12 V, 200 mA maximum).
Analog input 1.
CPOT
The default function is as accelerator reference (wiper contact
of the accelerator potentiometer).
Digital input active when connected to +B.
FW
The default function is as forward request; closing this input the
truck moves forward.
Digital input active when connected to +B.
BW
The default function is as backward request; closing this input
the truck moves backward.
Digital input active when connected to -B.
SEAT
The default function is as seat (or tiller) input.
CHA_R
Channel A of the right-hand side incremental encoder.
Positive supply for the right-hand side encoder and for
potentiometers (+5 V or +12 V, 200 mA maximum).
Digital input, active when connected to -B.
The default function is as lowering request. Closing the switch,
LOWER
NEVP output (A25) is activated according to the setpoint
defined by CPOT EVP (A22).
Digital input, active when connected to -B.
SPARE
The default function is not defined.
Digital input active when connected to +B.
QI/PB
The default function is as quick-inversion or brake-pedal input.
Analog input 4.
CPOT
The default function is as steering reference (wiper contact of
STEER
the steering potentiometer).
Negative supply for the left-hand side encoder, the left-hand
NENC_L
side thermal sensor and potentiometers.
Analog input 2.
The default function is as breaking reference (wiper contact of
the brake potentiometer).
Page 33/169
