2.3 Current ratings
Internal algorithms automatically reduce the maximum current limit when heat
sink temperature is above 85°C. Heat sink temperature is measured internally
near the power MOSFETs (see paragraph 6.6.1).
Two-minute ratings are referred to an inverter equipped with a base plate. No
additional external heat sink or fans are used for the 2-minute rating test. Ratings
are based on an initial base plate temperature of 40°C and a maximum base
plate temperature of 85°C.
The inverter can deliver the rated continuous current only if it is adequately
cooled. When it is equipped with its own finned heat sink, a proper dissipation is
obtained by applying a 100 m
it is customer's duty to design an adequate cooling system that can dissipate the
heat produced by the inverter, keeping its temperature below 85 °C. Otherwise,
the inverter will deliver a continuous RMS current lower than the rated one.
Page 12/169
Nominal DC
Maximum 2-min
voltage [V]
rated current [Arms]
24
36 / 48
72 / 80
96
Continuous rated
current [Arms]
2 x 550
2 x 500
2 x 450
2 x 400
2 x 350
2 x 550
2 x 500
2 x 450
2 x 400
2 x 350
2 x 275
2 x 400
2 x 350
2 x 300
2 x 250
TBD
3
/h airflow. In case it is provided with the base plate,
AFNZPxxx – DUALACE2 NEW GENERATION – User Manual
2 x 275
2 x 250
2 x 225
2 x 200
2 x 175
2 x 275
2 x 250
2 x 225
2 x 200
2 x 175
2 x 135
2 x 200
2 x 175
2 x 150
2 x 125
TBD
